Aluminium Foil heatseal coated blister foil
Zhenghui Printing&Packing Industrial Co.,ltd Supply all kinds of heatseal coated blister foil ,non printing or colored printing foil,the detailed information is as follows:
1.Introduction, heatseal coated blister foil
Temper,Alloy: H18, 8011
Thickness:0.020mm-0.030mm(before coating).
Width: 50-600mm(according to your requirement)
Core Inner diameter:76mm
Heat sealing strength: more than 7N/15mm
Primer or OP: about 1GSM
One side coated HSL for heat sealing with PVC/PVDC for packing tablet,capsules,etc. The other side is printed or coated primer for printing
2.Structure: heatseal coated blister foil
HSL/Alu foil/Printing layer/OP layer
HSL/Printing layer/Alu foil/Printing layer/OP layer
HSL/Printing layer/Alu foil/OP layer
HSL/Alu foil/OP layer
HSL/Alu foil/Primer(printable)
3.Technical data: heatseal coated blister foil
Appearance |
Clear;smooth;uniform coating,no more than 3 joint-points each 1000m,marked each joint-point,surface&side entangles tightly and neat. Tower-shaped, staggered &core falling free & severe damage are forbidden. |
Width Deviation |
±0.5mm |
Thickness Deviation |
±0.003mm |
Pinhole |
There are no dense, continual ,periodic pinhole. There are no pinhole with d≥0.3mm in 1m2. The pinhole with d=0.1-0.3mm≤1 in 1m2. |
Printing Quality |
The letter and design is correct,clear,fastness, non-fade in high-temperature heat seal process. |
Overprint precision ±0.5mm | |
Protecting Layer |
Non-desquamation by adhesive tape test |
Difference of Coated Volume of Adhesive Layer |
≤±10% |
Heat seal Strength of Adhesive Layer (N/15mm) |
≥7 |
Rupture Strength(KPa) |
≥98 |
Performance of Opening the Roll |
Protecting layer& Adhesive layer are not agglutinate |
3. other information:
| DIRECTION : | Generally printed or clear lacquer side is out with heat Seal coating inside. |
| CORE: | Material options: (a) Plastic (b) Aluminium (c) Card Board Core ID : 76 mm +/- 0.5 mm The length of the core is equal to the width of the web. |
| SPLICES: | Butt type made with 25 mm pressure sensitive tape. |
| REEL OUTER DIAMETER : | 250 +/- 10 mm for slit material, 400 +/- 10 mm for Jumbos |
| REEL WANDER: | Within +/- 1 mm |
| REEL/WEB WIDTH: | Plain: 45mm to 800 mm with a tolerance of +/- 0.5 mm. Printed: 45mm to 600 mm with a tolerance of +/- 0.5 mm |
| JOINTS PER REEL: | Maximum 2. Average less than 1. |
| PIN HOLES: | 0.025 and 0.03 mm foils are free from pin holes. In 0.02 mm foil, 40% of foil is free from pin holes, rest less than 10 PSM |
4.Packing: for heatseal coated blister foil ,Each roll will be packed in PP protection film,4 rolls in a carton .
5.Printing:for heatseal coated blister foil 1-6 colors printing
6.Delivery time:for heatseal coated blister foil 15-20days
,
Production Process:
Our Machine:
For heatseal coated blister foil ,we choose 10-15kgs a roll,each roll will be packed by PP film 4rolls in a carton,a 20ft container can load 18tons.
