Home > Electrical & Electronics > Breaker & Protector > Circuit Breaker > 10kV Circuit Breaker China

10kV Circuit Breaker China

US$ 50 - 100 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Shaanxi, China

Brand Name:

Type:

Vacuum

Contact Supplier Request Quote Chat Now

Xian Yuanshun Electrical Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xi'an

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shaanxi, China

Brand Name YS

Type Vacuum

10kV Circuit breaker china

1.10kV Circuit breaker china
2.Simple structure
3.high mechanical reliability

Main features:

Breaking excellent performance, arcing short time. On the shelves within the insulation and air to achieve. Can be allowed to carry disconnectors. , Long life, full capacity of not breaking 30 overhaul, insulation reliable. Simple structure, high mechanical reliability. Spring with actuator, Ⅲ-filthy silicone rubber casing and insulation ceramic vacuum chamber.

Main technical parameters:

Rated Voltage	12 kV
Current Rating	A 630,1250
Breaking rated short circuit currents	20 kA
Rated closing short circuit current (peak	50 kA
Rated current short-term tolerance	20 kA
Rated current peak tolerance	50 kA
Rated short duration	4 S
Mechanical life	10000,
:Breaking rated short-circuit breaking current number	30
Rated operating order	-0.3-s-s-a-a--180
Rated insulation level (altitude of 1000 meters): 1 minute frequency. Rating: Stem Test	42 kV
wet test (for the external insulation): 34 kV; lightning impulse withstand voltage	75 kV
:Full off time	≤ 0.125 S
Rated short duration	: 4 S
:Rated operating voltage and auxiliary circuit rated voltage (TAC, DC	220 V
Flow Release Current Rating	5 A

Apply to the following 12 kV and the electricity system, the role of a sub, a load current, overload and short circuit current use, but also to operate frequent places.
