HB1102 OIL RESISTANT FILLING MASTIC
Applications:
To provide oil resistance, sealing and insulation for oil-immersed cable termination and joints for heat shrink technology up to 15KV.
Features:
l Excellent oil resistance properties
l Good adhesion to metal like lead, copper and aluminium
l Good sticky to insulation tubing
l Operating temperature: -40℃to 90℃
l Standard color: brown
Technical properties:
Property |
Testing method |
Typical data |
Tensile strength |
GB/T 528-1998 |
≥0.1MPa |
Elongation at break |
GB/T 528-1998 |
≥950% |
Dielectric strength |
GB/T 1695-81 |
≥15KV/mm |
Dielectric constant |
GB/T 1693-81 |
6~8 |
Volume resistance |
GB/T 1692-1992 |
≥1.0x1012Ω•cm |
Adhesive to steel |
GB/T 2790-1995 |
3.0N/mm |
Dimensions:
Code |
Thickness(mm) |
Width(mm) |
Length(mm) |
Standard packing |
HB1102 |
2 |
30 |
360 |
1pcs/bag; 250bags/carton |
HB1102 |
2 |
30 |
500 |
3pcs/bag; 80bags/carton |
*Other sizes and packing are available on requested.
Related information:
The product is supplied as stripes or rolls of specified dimensions with release paper on both sides. Recommend to store in the original packing, protected from moisture, dust, heat and sunlight.
