Analogue TENS EMS Dual Medical Equipment
Simple to Use with less breakdown possibility b/c LCD screen is eliminated.
Great pricing but with loads of function: including DUAL channel,DUAL function (TENS/EMS), THREE modes (cycle burst, continuous, modulated)
TECHNICAL SPECIFICATIONS:
Channel: |
Dual, isolated between channels |
Pulse amplitude: |
Adjustable 0-80mA peak into 500 © load each channel, constant current |
Pulse Rate: |
2Hz-120Hz (adjustable). |
Pulse Width: |
a. 40-260¼s adjustable for TENS, b. 250¼s fixed for EMS. |
Timer: |
30, 60 minute and continue selectable |
FUNCTION MODES:
TENS:
B: Cycle Bursts, 2Bursts/sec, 9pulses/Burst, 100Hz, width is adjustable.
C: Continuous mode. Pulse rate, pulse width and intensity are full adjustable.
M: Modulated Width. Pulse width is automatically varied in an interval of 6 seconds. The modulation range of pulse width is from setting value to 35% less than the control setting value. And then returns to the setting value. Rate, width and intensity are fully adjustable.
EMS:
S: Synchronous.
A: Alternation.
On Ramp: Adjustable 1-8 seconds.
Cycle ON Time: Adjustable 1-30 seconds.
Cycle OFF Time: Adjustable 1-30 seconds.
Waveform: Asymmetrical Bi-phasic square pulse.
Max charge per pulse: 21micro-coulombs maximum.
Voltage: 0-110 Volt (Open Circuit).
Power Source: 9-Volt Battery.
Dimensions: 95mm(H) × 61.5mm(W) × 26mm(T).
Weight: Approx. 125grams (battery included).
All electrical specifications are ±10% except the amplitude is +/-20% (500© load).
