OEM Heating Exchanger Air Air Price for M30

OEM Heating Exchanger Air Air Price for M30 thumbnail-1
OEM Heating Exchanger Air Air Price for M30 photo-1
US$ 100 - 1,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Other, Condenser, Plate Heat Exchanger
Place of Origin:
Liaoning, China
Brand Name:
SUCCESS, SUCCESS
Contact Supplier Request Quote Chat Now
Liaoning Success Thermal Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, Condenser, Plate Heat Exchanger
Place of Origin Liaoning, China
Brand Name SUCCESS, SUCCESS
Model Number M30, M30
Certification Other, ISO9001:2008
After-sales Service Provided Overseas service center available

Specifications

1. Fast delivery
2. Over 10 years experience
3. Safe operation
4. Easy to install
5. Long functional life

Parameters

S30D-I

Heat transfer area of plate m2

1.1

Chevron depth mm

3.5

Chevron angle º

1

60

2

120

Chevron normal pitch mm

10.9

Equivalent diameter mm

7

Hole diameter mm

300

Center Distance of holes mm

H

1320

W

598

Center distance of suspension mm

1564

Cross section ofsingle passage mm2

3272

Overall dimension of plate mm

L

1705

W

982

The max. heat transfer coefficient

                   (water to water)W/ m2.ºC

7500

The max. Working temp.ºC

180

The max. testing pressure Mpa

1.6

The max. flow rate M3/h

1310







































































No.

ASSY Area m2

No.of plate

The max. testing pressure Mpa

Dimension mm

Theoretical weight(kg)

   L

W

H

1

80

73

1.6

1115

1125

2000

3220

2

110

100

1.6

1315

1125

2000

3450

3

140

127

1.6

1515

1125

2000

3680

4

170

155

1.6

1715

1125

2000

3920

5

200

182

1.6

1815

1125

2000

4150

6

230

209

1.6

2015

1125

2000

4380



  OEM heating exchanger air air price for M30OEM heating exchanger air air price for M30
