Help CenterM20M Stainless Plate Heat Exchanger
Related Products
-
S10M-24 Panel Coils Heat ExchangerUS$ 5,000 - 10,000MOQ: 1 Set -
BRV20 Gasketed Cleaning Heat ExchangerUS$ 1,000 - 10,000MOQ: 1 Set
-
30 Plate Heat ExchangerUS$ 1,000 - 10,000MOQ: 1 Set
-
Replace 30 Gea Plate Heat ExchangerUS$ 500 - 1,000MOQ: 1 Set
-
BRV45 Gasketed Heat Exchanger for SaleUS$ 100 - 1,000MOQ: 1 Set
Specifications
1small heat,resistance loss plate2 we are the source
3 flexible operation plate
4 can be your OEM
plate heat heat exchanger
1. Material
Plate Material: 304(0Cr18Ni9),321(0Cr18Ni10Ti),316(0Cr17Ni12Mo2),316L(00Cr17Ni14Mo2),titanium(TA1-A),254SMO,nickel alloy
Gasket Material: NBR rubber, EPDM RUBBER, Fluorous rubber, Neoprene rubber, silicone rubber, asbestos rubber sheet.
Rack material: carbon steel, stainless steel, outsourcing stainless steel
Rod material: Galvanized steel, stainless steel
Interface Material: rubber, carbon steel, stainless steel
2.Design and Selection
The plate heat exchanger produced by our company strictly follows the rule listed in GB16409-1996 "plate heat exchanger," to design, manufacture and test.
3. Overview
Plate heat exchanger is compact and efficient heat exchange equipment, using the metal corrugated sheet as the major heat transfer agent. The fluid flows through the inner-flow mesh panel which is made up by the corrugated plates. Because after the plates assembly, they form a special channel which can generate turbulence under low Reynolds number, and the turbulence can easily destroy the fluid boundary layer,that greatly reduces thermal resistance and efficiently enhances the heat transfer, moreover, with no scale.
4.Application
1,Chemical Industry. Alkaline Liquid Cooling; Acid Liquid Cooling; Manufacturing Processing Cooling; Water Circulation Cooling; Kerosene Oil Cooling; Salt Solution Cooling; Ethanol Cooling
2, Steel Industry: Mould Cooling; Boiler Water Cooling; Emulsion Cooling; Conticaster Cooling; Hydraulic Oil Cooling; Ammonia Cooling; Coke-oven Plant Water Cooling; Machinery Coolant Cooling.
3, Paper Industry Waste Water Cooling; Washing Water Cooling; Waste Water Evaporation; Heating Recovery System; Wood Pulp Condensation
4, Food & Beverage Juice Concentration; Syrup Heating; Extracting Water Heating; Original Juice Heating; Concentrated Juice Heating; Syrup Heating; Diluted Juice Heating; Juice with Carbonic Acid Gas Heating
5, Oil & Gas Industry Crude Oil Heating; Crude Oil Cooling; Oil Well Injection Water Heating
6, HVAC District Heating; District Cooling; Domestic Hot Water; Air Conditioner Cooling; Refrigeration; Ventilation; Vaporizer; Condenser 7, Marine Industry Central Heating and Cooling, Fresh Water generating etc.
