Specifications
1.30 sets per day2.lead time assurance
3.OEM and ODM
4.ISO 9001 2000
5.with over 10 years experience
food industry wide gap heat exchanger for edible oil
Brief Introduction
We are a professional manufacturer for heat exchanger and spare parts, located in Haicheng City, Liaoning Province, China.
Our main product including plate heat exchanger,gasket, plate, mould for gasket and plate as well as other accessories related with PHE with competitive price. Starting out as a manufacturer of PHE gasket in1996, we have enjoyed a leading reputation in both domestic and overseas markets.
Plate Heat Exchanger Material
1. PLATE MATERIAL
Stainless steel—clean water, river water, edible oil, mineral oil
Titanium and titanium palladium—sea water, salt water, salt.
Hastelloy—sulfuric acid, hydrochloric acid, phosphoric acid
2. GASKET MATERIAL
NBR (nitrile rubber)—water, sea water, mineral oil, brine
HNBR—high temperature mineral oil, high temperature water
EPDM(ethylene-propylene)—hot water, water vapor, acids,alkalis.
HEPR—high temperature water vapor, acids and alkalis fluid.
FKM—strong acids and strong alkalis
3. FRAME MATERIAL
Standard: plastic coated carbon steel
Special: stainless steel covering
Plate Heat Exchanger Structure
Plate Heat Exchanger Model List(part of)
Model |
B |
H |
B1 |
BC |
H1 |
H2 |
M |
DN |
Max Flowrate (m3/h) |
Max. testing pressure Mpa |
S6D/S-I |
340 |
900 |
140 |
270 |
139 |
640 |
18 |
50 |
50 |
2.5 |
S6D/S-I |
340 |
900 |
140 |
270 |
139 |
640 |
18 |
50 |
50 |
2.5 |
S6D/S-II |
340 |
1146 |
140 |
270 |
139 |
886 |
18 |
50 |
50 |
2.5 |
S8D/S-I |
425 |
930 |
203 |
355 |
156 |
380 |
18 |
80 |
90 |
2.0 |
S10D/S-I |
500 |
1121 |
223 |
400 |
225 |
719 |
20 |
100 |
141 |
1.6 |
S10D/S-II |
500 |
1244 |
223 |
400 |
225 |
842 |
20 |
100 |
141 |
1.6 |
S10D/S-III |
500 |
1450 |
223 |
400 |
225 |
1048 |
20 |
100 |
141 |
1.6 |
S15D/S-I |
630 |
1496 |
298 |
510 |
265 |
996 |
22 |
150 |
318 |
2. 0 |
S15D/S-II |
630 |
1794 |
298 |
510 |
265 |
1294 |
22 |
150 |
318 |
2.0 |
S15D/S-III |
630 |
2092 |
298 |
510 |
265 |
1592 |
22 |
150 |
318 |
2.0 |
S20D/S-I |
740 |
1647 |
341 |
620 |
287 |
1095 |
22 |
200 |
565 |
2.5 |
S20D/S-II |
740 |
2030 |
341 |
620 |
287 |
1478 |
22 |
200 |
565 |
2.5 |
S20D/S-III |
740 |
2352 |
341 |
620 |
287 |
1739 |
22 |
200 |
565 |
2.5 |
Plate Heat Exchanger Manufacture
Details of Plate Heat Exchanger
