Specifications
1.Reliability2.High heat exchange efficiency
3.Safe operation
4.Easy to install
5.Long functional life
gasketed plate type air ss316 heat exchanger
Specification Parameters for Heat exchanger
No. |
ASSY Area m2 |
No.of plate |
The max. testing pressure Mpa |
Dimension mm |
Theoretical weight(kg) |
||
L |
W |
H |
|||||
1 |
30 |
101 |
1.6 |
1030 |
500 |
1244 |
450 |
2 |
40 |
134 |
1.6 |
1230 |
500 |
1244 |
500 |
3 |
45 |
151 |
1.6 |
1430 |
500 |
1244 |
525 |
4 |
50 |
167 |
1.6 |
1630 |
500 |
1244 |
550 |
5 |
55 |
183 |
1.6 |
1730 |
500 |
1244 |
575 |
6 |
60 |
201 |
1.6 |
1830 |
500 |
1244 |
600 |
Company Introduction
Liaoning Success Thermal Technology Co., Ltd. is a professional manufacturer and exporter that is specialized in the design, development and production of plate heat exchangers, plate heat exchanger gaskets and moulds as well as other plate heat exchanger accessories.
Covering an area of 12,000 square meters, we now have over 300 employees and currently export over 30% of our products worldwide. Our company has two subsidiaries, namely Haicheng YUHUA Mould Manufacturer Co., Ltd. and Haicheng YUFENG Technology Co., Ltd., which produce the moulds and gaskets for PHE separately.
SUCCESS has adopted the policy of “QUALITY FIRST, CUSTOMER SUPREME” through continuous technological advanced manufacturing and testing equipment to meet customers’ requirement and quality criteria.
Product Range:
Plate Heat Exchanger, Plates, Gaskets, Moulds, Frame, Connection, Flange etc.
More detail:
MATERIAL OF PHE
1. PLATE MATERIAL
Stainless steel—clean water, river water, edible oil, and mineral oil
Titanium and titanium palladium—sea water, salt water, salt.
Hastelloy—sulfuric acid, hydrochloric acid, phosphoric acid
2. GASKET MATERIAL
NBR (nitrile rubber)—water, sea water, mineral oil, brine
HNBR—high temperature mineral oil, high temperature water
EPDM(ethylene-propylene)—hot water, water vapor, acids and alkalis.
HEPR—high temperature water vapor, acids and alkalis fluid.
FKM—strong acids and strong alkalis
3. FRAME MATERIAL
Standard: plastic coated carbon steel
Special: stainless steel covering
4. CONNECTION MATERIAL
Standard: EPR and NBR
Special: Stainless steel and titanium
5. ACCESSORIES
The insulation cover of heat exchanger can also be provided according to customer requirement.
CERTIFICATIONS:
