Full Electric Stacker
US$ 10 - 1,000
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
YI-LIFT
Model Number:
BKW1568
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Manual Material Lift Auluminum LGA SeriesNegotiableMOQ: 6 Pieces -
Hand StackerNegotiableMOQ: 3 Pieces
-
Full Electric Stacker Max Lifting 6800mmUS$ 10 - 1,000MOQ: 2 Pieces
-
Semei-electric Stacker MW Series Straddle LegNegotiableMOQ: 6 Pieces
-
1600mm 500-2000kg Manual Stacker EPSUS$ 100 - 500MOQ: 2 Pieces
Place of Origin
Jiangsu, China
Brand Name
YI-LIFT
Model Number
BKW1568
Dimension(L*W*H)
BKW1568
Certification
CE,GS,SGS,ISO9001,BV
Warranty
2 years warrenty
After-sales Service Provided
Engineers available to service machinery overseas
- Heavy duty design with top quality mast construction.
- Powerfull drive wheel and power unit made in Europe
- Top quality electronic control system from Curtis .
- conforms to EN1757-1:2000,EN1726.
| Model | BKW1568 | ||
| Power Type | battery powered | ||
| Operation Type | pedestrian | ||
| max. lift weight Q | kg | 1500 | |
| lift weight at Max height | kg | 300 | |
| load center C | mm | 600 | |
| overall length L1 | mm | 1990 | |
| overall width W | mm | 1510 | |
| Min.overall height H1 | mm | 2950 | |
| forks dimension L×b×m | mm | 1000×100×35 | |
| outside width of forks D | mm | 230~790 | |
| Ground Clearance x | mm | 29 | |
| wheel base L0 | mm | 1400 | |
| wheel material | PU | ||
| driving wheel size | mm | φ250×80 | |
| front wheel size | mm | φ78×70 | |
| balance wheel size | mm | φ150×75 | |
| min. steering radius Wa | mm | 1600 | |
| width of aisle | mm | ≥2500 | |
| max. lift height H | mm | 6800 | |
| max. overall size H2 | mm | 7580 | |
| min.height of forks H3 | mm | 65 | |
| travel speed(laden/unladen) | km/h | 4.0/5.5 | |
| lift speed(laden/unladen) | mm/s | 90/160 | |
| lower speed(laden/unladen) | mm/s | 95/120 | |
| brake type | electromagnetic | ||
| power of driving motor | Kw | 1.2 | |
| power of lift motor | Kw | 3.0 | |
| battery capacity/voltage | Ah/V | 240/24 | |
| weight of battery | kg | 210 | |
| net weight(without battery) | kg | 1280 | |
| Min. width of aisle refers to 1200mm×1000mm pallet. | |||
