Lift Table with full curtain

FOB Price

USD $20 - $20,000 / Piece

2 Pieces(Min.Order)

Supply Ability 500 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

You May Like

Product Details

Place of Origin	Jiangsu, China		Brand Name	YI-LIFT
Model Number	BSS

Product Description

Heavy Duty Design

HW series lift tables meet EN norm and ANSI/ASME safety standards.

These models can be used in above-floor or in-floor pit applications.

Standard Safety Features

Upper platform lifted with aluminum safety bar preventing descent on contact with obstructions.

Low-tention (24V) control box with up-down buttons.

Internal power pack equipped with relief valve against overloading and compensated flow valve for controlled lowering speed.

Heavy duty cylinders with drainage system and check valve to stop the lift table lowering in case of hose burst.

Safety clearance between scissors to prevent trapping during operation.

Other Standard Features

Self lubricating bushings on pivot points.

Removable lifting eye to facilitable handling and lift table installation.

High quality AC power packs are made in Europe.

Model	Capacity	Lowered Height	Raised Height	Platform Size	Base Frame Size	Lift Time	Power Pack	Net Weight
	(kg)	(mm)	(mm)	(mm)	(mm)	(second)		(kg)
HW1001	1000	205	990	820×1300	680×1266	20~25	380V/50HZ, AC 1.1kw	160
HW1002	1000	205	990	1000×1600	680×1266	20~25		186
HW1003	1000	240	1300	850×1700	680×1600	30~35		200
HW1004	1000	240	1300	1000×1700	680×1600	30~35		210
HW1005	1000	240	1300	850×2000	680×1600	30~35		212
HW1006	1000	240	1300	1000×2000	680×1600	30~35		223
HW1007	1000	240	1300	1700×1500	1600×1362	30~40	380V/50HZ, AC 1.1kw	365
HW1008	1000	240	1300	2000×1700	1600×1362	30~40	380V/50HZ, AC 1.1kw	430
HW2001	2000	230	1000	850×1300	785×1255	20~25	380V/50HZ,AC 2.2kw	235
HW2002	2000	230	1000	1000×1600	785×1255	20~25	380V/50HZ,AC 2.2kw	268
HW2003	2000	250	1300	850×1700	785×1630	25~35	380V/50HZ,AC 2.2kw	289
HW2004	2000	250	1300	1000×1700	785×1630	25~35		300
HW2005	2000	250	1300	850×2000	785×1630	25~35		300
HW2006	2000	250	1300	1000×2000	785×1630	25~35		315
HW2007	2000	250	1400	1700×1500	1630×1435	25~35	380V/50HZ,AC 2.2kw	415
HW2008	2000	250	1400	2000×1800	1630×1435	25~35	380V/50HZ,AC 2.2kw	500
HW4001	4000	240	1050	1200×1700	930×1600	30~40	380V/50HZ,AC 2.2kw	375
HW4002	4000	240	1050	1200×2000	930×1600	30~40		405
HW4003	4000	300	1400	1000×2000	930×1980	45~50		470
HW4004	4000	300	1400	1200×2000	930×1980	45~50		490
HW4005	4000	300	1400	1000×2200	930×1980	45~50		480
HW4006	4000	300	1400	1200×2200	930×1980	45~50		505
HW4007	4000	350	1300	1700×1500	1665×1432	35~45	380V/50HZ,AC 2.2kw	570
HW4008	4000	350	1300	2200×1800	1665×1432	35~45	380V/50HZ,AC 2.2kw	655
HW6001	6000	380	1150	1700×1000	1600×990	25~35	380V/50HZ,AC 2.2kw	475

Note: Specification and materials are subject to change without notice.
