Bridge Bearing Making Machine

Name: Bridge Bearing Making Machine
Brand: Yahua
SKU: 128418111
Availability: InStock

US$ 10,000 - 56,500 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

Yahua

Qingdao Yahua Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name Yahua

Model Number XLB

Voltage According to your voltage

Power(W) According to the machine

Dimension(L*W*H) According to the machine

Weight According to the machine

Certification ISO9001

Warranty 1year, One year

After-sales Service Provided Engineers available to service machinery overseas

bridge bearing making machine

We are professional manufacturer for production line of bridge bearing or any other kind of rubber products.

Machine can be customized according to your special requirements.

Engineers are available to work overseas.

Please contact me visa my whatsapp:+8615853204222 or skype:kikizhang712

Model		*XLB-D100010001*	*XLB-D/Q12001200**	*XLB-D600600**	*XLB-D4004002*
1	Norminal mouldning power(MN)	2.50	3.15	1.60	0.5
2	Plate size (mm)	1000*1000	1200*1200	600*600	400*400
3	Plate pressure (Mpa)	2.5	2.19	4.4	3.1
4	Piston diameter(mm)	450	600	360	200
5	Number of hydraulic cylinder (pcs)	1	1	1	1
6	Piston stroke(mm)	300	800	300	250
7	Distance between hot plate(mm)	150	800	300	125
8	Working layer number	1	1	1	2
9	Pressure of working fluid (Mpa)	15.7	17.7	15.7	16.0
10	Total heat power(KW)	24	36		9.0
11	Heat type	electricity	vapor/electricity	electricity	electricity
12	Maximum working temperature	200°C	200/170 °C	200 °C	200 °C
13	Configuration type	Frame	Frame	pillar	pillar
