Help CenterAutomatic Rubber Platen Vulcanizing Press/Rubber Mat Making Machine
Related Products
-
Promotion!!Rubber Gasket Making Machine/Automotive Electric Heating Rubber Curing PressUS$ 3,450 - 36,500MOQ: 1 Set -
Promotion!!Rubber Mouse Pad Making Machine/Rubber Gasket Making Machine/Rubber Sheet Curing PressUS$ 3,450 - 36,500MOQ: 1 Set
-
Solid Type Vulcanizer/Rubber Sealing Washer Moulding PressUS$ 4,000 - 69,000MOQ: 1 Set
-
Promotion!!Rubber Mouse Pad Making Machine/Automotive Electric Heating Rubber Sheet Curing PressUS$ 3,450 - 36,500MOQ: 1 Set
-
Germany Technology 2 Stations Rubber Vulcanizer/Rubber Wheel Plate Rubber Vulcanizer/Curing PressUS$ 3,500 - 45,600MOQ: 1 Set
Specifications
1.rubber platen vulcanize machine2.used widely, good sales
3.automatic in/out mold
4.PLC control, ejector device
5.ISO
We are Qingdao Yahua Machinery CO.,LTD. Our main products are plate vulcanizing machine, curing press, rubber machine, conveyer belt vulcanizing press, Rubber crushing mill, Rubber refining mill, rubber tiles vulcanizing press, tire building machine, rubber kneader, two-roll mixing mill and so on.
The products have been exported to many countries, such as America, Canada, Australia, South Korea, and Southeast Asia, Middle-east, etc .
If you interested in our products mentioned above. Kindly let us know by return email.
Contact person:Bella Xue
Skype:bella.xue1990
Phone:0532-83132191/83137817
| description of rubber platen vulcanize machine | 1. rubber platen vulcanize machine 2. It is used for vulcanizing all kinds of rubber and plastic mould products, and non-mould products. 3. It is used for vulcanizing all kinds of rubber and plastic mould products, and non-mould products. 4. Frame type, rubber platen vulcanize machine is different from the column type, it is allowed to install larger diameter hydraulic cylinder, reducing the quantity of cylinders, with simple structure, and little maintain wok. The frame can bear more stress and it has cheap price, nice surface, easy to operate. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| parameter of rubber platen vulcanize machine |
rubber platen vulcanize machine:
|
Technical Parameter:
Type |
XLB-DQ400*400*2 |
XLB-DQ600*600*2 |
XLB-DQ750*850*2 |
XLB-DQ1000*1000*2 |
XLB-DQ1500*1500*2 |
Total pressure |
0.50 MN |
1.00 MN |
1.60 MN |
4.00 MN |
8.00 MN |
Plate size |
400*400 mm |
600*600 mm |
750*850 mm |
1000*1000 mm |
1500*1500 mm |
Plate clearance |
125 mm |
125 mm |
125 mm |
125 mm |
125 mm |
Working layer nuber |
2 |
2 |
2(4) |
2(4) |
2(4) |
Piston stroke |
250 mm |
250 mm |
250(500) |
250(500) |
250(500) |
Plate pressure |
3.1 Mpa |
2.8 Mpa |
2.5 Mpa |
4.0 Mpa |
3.6 Mpa |
Motor power |
2.2 kw |
3 kw |
3 kw |
5.5 kw |
5.5 kw |
weight |
1300 kg |
3500 kg |
6500 kg |
11000 kg |
22000 kg |
