Help CenterManual&Automatic Rubber Moulding Press/Rubber Mat Manufacturing and Vulcanizing Machine
Related Products
-
EVA Slipper Industrial MachineryUS$ 2,800 - 16,800MOQ: 1 Set -
Chinese Manufacture of Slipper MachineUS$ 2,800 - 16,800MOQ: 1 Set
-
China Slipper MakingUS$ 6,500 - 46,750MOQ: 1 Set
-
China Slipper Making MachineUS$ 6,500 - 46,750MOQ: 1 Set
-
HOT!Auto Control Rubber Slipper Making Machine/Rubber VulcanizerUS$ 5,600 - 25,800MOQ: 1 Set
Specifications
1.The machine adopts PLC control.2.Advanced technique,excellent performance,
3.Save power
4.ISO9001:2008
RUBBER VULCANIZER(MANUAL & AUTOMATIC):
1. This vulcanizing machine is used for all kinds of vulcanizing mould,rubber and plastic mould products,and non-mould products.
2. Being a column structure and dowward pressing trpe,the heating plate opens by the seif-weight of the heating plate,platfrom and plunger.The rising of the plunger makes the heating plate close while the hydraulic oil provides the pressure.
3. This engine base is combined together with the cylinder and base frame,which is made of ductile iron to increase the cylinder intensity and abrad ability,The cylinder is fitted with the sealing washer made of the oil-resisting rubber for the sealing purpose.
4. By moving the operational handle of the control value to the two different positions,the heating plate can open and close.
5. It uses the electric pipe for heating,thus makes the workshop clean with easy and reliable operation.
6. We can design and manufacture all kinds of no-standard rubber machinery according to the requirement of the customers.
Technical Parameter:
Type | XLB-DQ400*400*2 | XLB-DQ600*600*2 | XLB-DQ750*850*2 | XLB-DQ1000*1000*2 | XLB-DQ1500*1500*2 |
Total pressure | 0.50 MN | 1.00 MN | 1.60 MN | 4.00 MN | 8.00 MN |
Plate size | 400*400 mm | 600*600 mm | 750*850 mm | 1000*1000 mm | 1500*1500 mm |
Plate clearance | 125 mm | 125 mm | 125 mm | 125 mm | 125 mm |
Working layer nuber | 2 | 2 | 2(4) | 2(4) | 2(4) |
Piston stroke | 250 mm | 250 mm | 250(500) | 250(500) | 250(500) |
Plate pressure | 3.1 Mpa | 2.8 Mpa | 2.5 Mpa | 4.0 Mpa | 3.6 Mpa |
Motor power | 2.2 kw | 3 kw | 3 kw | 5.5 kw | 5.5 kw |
weight | 1300 kg | 3500 kg | 6500 kg | 11000 kg | 22000 kg |
THE PRODUCT PHOTOS:
Model | XLB-D1000*1000*1 | XLB-D/Q1200*1200 | XLB-D600*600 | XLB-D400*400*2 | |
1 | Norminal mouldning power(MN) | 2.50 | 3.15 | 1.60 | 0.5 |
2 | Plate size (mm) | 1000*1000 | 1200*1200 | 600*600 | 400*400 |
3 | Plate pressure (Mpa) | 2.5 | 2.19 | 4.4 | 3.1 |
4 | Piston diameter(mm) | 450 | 600 | 360 | 200 |
5 | Number of hydraulic cylinder (pcs) | 1 | 1 | 1 | 1 |
6 | Piston stroke(mm) | 300 | 800 | 300 | 250 |
7 | Distance between hot plate(mm) | 150 | 800 | 300 | 125 |
8 | Working layer number | 1 | 1 | 1 | 2 |
9 | Pressure of working fluid (Mpa) | 15.7 | 17.7 | 15.7 | 16.0 |
10 | Total heat power(KW) | 24 | 36 |
| 9.0 |
11 | Heat type | electricity | vapor/electricity | electricity |
electricity
|
12 | Maximum working temperature | 200°C | 200/170 °C |
200 °C
| 200 °C
|
13 | Configuration type | Frame | Frame | pillar |
pillar
|
Service after sale:
We give one year quality guarantee and long-term technical support. We also can train your workers for free. If you need, we can install and assemble the rubber hydraulic vulcanizing press machine in your workshop. And you should pay for the necessary costs, according to the international tradition.
Qingdao Yahua Rubber Machinery Co.,Ltd is 100% RUBBER MACHINERY manufacturer
Passed ISO9001:2008 certificate
Contact Person: John
Office phone: 0532-83132191
Office Fax: 0532-831312191
