Flat Plate Solar Hot Water Panel With Black Chrome Coating

Name: Flat Plate Solar Hot Water Panel With Black Chrome Coating
Brand: Dr.X
SKU: 128408451
Availability: InStock

US$ 100 - 150 MOQ: 1 Piece

Key Specifications

Type:

Flat-Plate

Pressure:

Pressurized

Circulation Type:

Indirect / Closed Loop (Active)

Jiangsu Dr. Xia Solar Energy Inc.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Type Flat-Plate

Pressure Pressurized

Circulation Type Indirect / Closed Loop (Active)

Heating System Other, split type

Connection Type Other, flat plate type

Installation Other, pitched roof mounted

Housing Material Other, aluminum alloy

Certification CE

Capacity 150

Place of Origin Jiangsu, China

Brand Name Dr.X

Model Number DX/FCB

Flat plate solar hot water panel with black chrome coating

Technical Specification

Model	DX/FCA-2000/1000/80	DX/FCBC-2000/1000-80	DX/FCB-2000/1000-80	DX/FCT-2000/1000/80
Coating	Anodic Oxidation	Black chrome	Black chrome	Blue coating
Welding	Laser	Ultrasonic	Laser	Laser
Material of Absorber	Copper &Aluminum	Copper	Copper &Aluminum	Copper &Aluminum
Size & Quantity header pipe	22*08mm 2PCS
Size &Quantity branch pipe	10*0.6mm 7PCS
Absorption rate	0.90±0.03	0.93±0.03	0.92±0.03	0.94±0.02
Reflection rate	0.18±0.05	0.10±0.05	0.10±0.05	0.05±0.02
Collector size	2000 x 1000 x 80
Frame color	Silver/Black/Champagne
Gross area	2 sqm
Absorber area	1.85sqm
Sealing	EPDM
cover material	Ultra white and low iron fabric surface tempered glass
Cover transmission	92%
Back plate material	0.30mm galvanized steel
Insulation	30mm glass wool
Max working pressure	0.6MPa
weight	37kg	37kg	38kg	38kg
