371049-B21 4gb ddr ram with ett chips server memory

Specifications

371049-B21 4gb ddr ram with ett chips server memory

Original brand server ram 4GB (2x2GB) PC2700 ECC Registered DDR SDRAM DIMM Memory Kit

Model No.: 371049-B21

Application: Server

Function: REG ECC-DIMM

Port: DIMM 184 pin

Type: DDR SDRAM

Ram Capacity: 2x2GB

Frequency: 333MHZ PC2700

Data Integrity Check: ECC

Feature: Dual Rank

DL585 PC2700,DL585 G1

When upgrading memory DIMMs 1A and 3A must match. DIMMs 5B and 7B DIMMs 2C and 4C and DIMMs 6D and 8D must match and must be installed as a pair. When DIMMs 1A and 3A are populated the system is automatically configured for 2:1 interleaving. When all 4 banks are populated the system is automatically configured for 4:1 interleaving. When four six or eight DIMMs are populated with identical DIMMs the system is automatically configured for bank interleaving.

NOTE: In the online spare configuration the ROM automatically configures the last populated bank as the spare memory. If only banks A and B are populated bank B is the spare bank. If banks A B and C are populated bank C is the spare bank Online spare memory is configured through RBSU.

NOTE: Mirrored Memory uses mirrored banks to provide a high level of memory redundancy. Customer chooses to implement or not: User selectable via BIOS and default is off.

1.A dual inline memory module (DIMM) consists of a number of memory components (usually black) that are attached to a printed circuit board (usually green). The gold pins on the bottom of the DIMM provide a connection between the module and a socket on a larger printed circuit board. The pins on the front and back of a DIMM are not connected to each other.

2.Each 240-pin DIMM provides a 64-bit data path (72-bit for ECC or registered or Fully Buffered modules).  Standard DDR3 240-pin DIMMs are currently available in DDR3 PC3-8500 SDRAM. Additional speeds will be added as the technology becomes available.

3.The number of black components on a 240-pin DIMM can vary, but it always has 120 pins on the front and 120 pins on the back, for a total of 240. 240-pin DIMMs are approximately 5.25 inches long and 1.18 inches high, though the heights can vary. While 240-pin DDR3 DIMMS, 240-pin DDR2 DIMMs, 184-pin DDR DIMMs, and 168-pin DIMMs are approximately the same size, 240-pin DIMMs and 184-pin DIMMs have only one notch within the row of pins.
