Huawei OSN 550
USD $1,500 - $1,750
1 (Min.Order)
- 0 per Month
- HongKong
You May Like
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Brand Name: | HUAWEI | Model Number: | OSN 550 |
Product Description
02113412 | TNMB2CASE | AC Assembly Chassis |
OptiX OSN 550 Product Specifications
System Features | ||||||
---|---|---|---|---|---|---|
Subrack dimensions | 88 mm (H) x 442 mm (W) x 220 mm (D) | |||||
Switching capacity | Packet: 60 Gbit/s and TDM: 20 Gbit/s (higher order), 5 Gbit/s (lower order) | |||||
Service slots | 6 service interface slots | |||||
Highly reliable design | 1+1 hot backup for power supply modules 1+1 hot backup for the system control boards 1+1 hot backup for the cross-connect and synchronous timing boards | |||||
Supported interfaces | Packet transport interfaces | E1, ch STM-1, ATM STM-1, FE/GE/10GE | ||||
MSTP interfaces | STM-1/4/16, E1/E3/T1/T3, FE/GE | |||||
WDM interfaces | 40-channel DWDM interfaces, compliant with ITU-T G.694.1 8-channel CWDM interfaces, compliant with ITU-T G.694.2 | |||||
Networking Mode | Supports pure packet,hybrid (packet + SDH) or SDH networking Supports WDM networking Supports single-fiber bidirectional transmission | |||||
Power Supply | -38.4~-72V DC; 110/220V AC | |||||
Installation | ETSI rack with 300mm/600mm depth 19-inch rack Wall-mount Desktop Out-door cabinet | |||||
Weight | Net weight of the subrack (no board or fan): 2.78 kg Typical configuration: 5.8kg | |||||
Operation Environment | Temperature Relative Humidity Long term: -5°C ~ 55°C 10% ~ 90% Short term: -5°C ~ 65°C 5% ~ 95% | |||||
Packet Transport Features | ||||||
Service features | E-Line and E-LAN QinQ MPLS-TP based VPWS and VPLS Multi-section pseudo-wire (MS-PW) TDM PWE3: CESoPSN and SAToP, compression of idle timeslots ATM/IMA PWE3 ETH PWE3 IGMP SNOOPING V2 Blacklist, Broadcast packet suppression, ACL VLAN SWAP | |||||
QoS features | DiffServ mode based on traffic classification Simple traffic classification, complex traffic classification, per hop behavior (PHB), and ACL Committed access rate (CAR) PQ scheduling priority, weighted round robin (WRR) and PQ+WRR queuing Tail drop and weighted random early detection (WRED) Eight priority queues Shaping based on port scheduling priority | |||||
Hardware-based OAM | MPLS OAM | LSP/PW OAM: FDI, BDI CV, FFD, TraceRoute, Ping CES PW VCCV | ||||
MPLS-TP OAM | LSP/PW OAM: CC,LB,LT AIS,RDI LM,DM LCK,TST CSF | Section OAM: CC,LB RDI LM,DM LCK,TST | ||||
Ethernet OAM | ETH-CC(Continuity Check),ETH-Loopback,ETH-Link Trace Remote Loopback,Remote Fault Detection | |||||
ATM OAM RMON(RFC 2819) Flexible design with multiple protocols | ||||||
Carrier-class protection | LSP/PW Linear protection MPLS-TP Ring protection ERPS(G.8032) Anti multifailure protection based on MS-PW Link aggregation group (LAG) protection LPT STP/RSTP/MSTP IMA protection 1+1 and 1:1 Linear MSP | |||||
Clock synchronization | Two external clock inputs/outputs (2 MHz or 2 Mbit/s) Two external time signals(1pps+TOD) Adaptive clock recovery (ACR) Synchronous Ethernet IEEE 1588v2 | |||||
MSTP Features | ||||||
Carrier-class protection | SDH Network Protection 2-fiber MS-SP Ring; 1+1, 1:n (n<=14) Linear MSP; SNCP; Fiber shared virtual path protection; DNI (ITU-T G.842) Ethernet Service Protection RSTP, LAG, LPT | |||||
Clock synchronization | Two external clock inputs/outputs (2 MHz or 2 Mbit/s) Line clock source Tributary clock source |
