Help Center350 Cargo Trailer
US$ 3,000 - 5,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Full Trailer
Material:
Steel
Certification:
CE
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Full Trailer
Material
Steel
Certification
CE
Size
Crane Arm:3.5 M
OEM No.
Grapple Crane 350
Max Payload
1500kg
Place of Origin
Zhejiang, China
Brand Name
4WMOTO
Model Number
Grapple Crane 350
Specifications
1.Length of crane arm:3.5m2.4x4 with wheeldrive
3.Hydraulic winch
4.Hydraulic Tipping Box
| Crane 350 Specification | |
| Model Name: | Grapple Crane 350 -I without automatic rolldrive |
| Grapple Crane 350-II 4x4 with automatic rolldrive | |
| Engine: | 7HP/5kw, pull start |
| Max rotary speed: | 3000r/m |
| Pressure of oil pump: | 16MPa |
| Pump supply oil flow: | 4ML/R |
| Working temperture: | -40°Cto 80°C |
| Length of crane arm: | 3.5M |
| Lifting capacity of Max.arm reach: | 200kg |
| Swing angle: | +-90°C |
| Hydraulic Oil Tank: | 7.2L |
| Fuel Tank: | 4L |
| Weight of crane: | 90kg |
| Whole machine weight of Crane 350-I ; | 580kg |
| Whole machine weight of Crane 350-II: | 630kg |
| Max loading of trailer: | 1500kg |
| 2006/42/EC certification | |
| Specification of hydraulic winch | |
| remote control: | waterproof |
| Remote control area | 30M |
| Rated line pull: | 800KG |
| Speed: | 10-25m/min |
