H.264 Standalone Dvr,Cctv Standalone Security Cms D1+cif 8channel Dvr

H.264 Standalone Dvr,Cctv Standalone Security Cms D1+cif 8channel Dvr thumbnail-1
H.264 Standalone Dvr,Cctv Standalone Security Cms D1+cif 8channel Dvr thumbnail-2
H.264 Standalone Dvr,Cctv Standalone Security Cms D1+cif 8channel Dvr photo-1
H.264 Standalone Dvr,Cctv Standalone Security Cms D1+cif 8channel Dvr photo-2
Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Joney
Model Number:
DVR-6008S
Contact Supplier Request Quote Chat Now
Shenzhen Joney Security Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Joney
Model Number DVR-6008S

Specifications

High Quality 8 Channels Dvr
1. 8 ch audio in/1 out
2. HDMI, VGA output up to 1080p
3. 8sync realtime playback




Product Description


H.264 Standalone Dvr,Cctv Standalone Security Cms D1+cif
8channel Dvr

High Quality  8 Channels Dvr

H.264 Standalone Dvr,Cctv Standalone Security Cms D1+cif 8channel Dvr



DVR Main Feature

High Quality  8 Channels Dvr
Overview

 8 channel video inputs
  8 ch audio in/1 out
All channel@ D1(4CIF) realtime recording
HDMI, VGA output up to 1080p
8ch alarm in & 1ch relay out
8sync realtime playback
  2SATA, 2 USB, RS485, 1 RJ45(100M)

> Up to 8 cameras with 1080p realtime preview
> H.264 dual-stream video compression
> All channel D1(4CIF) realtime recording
> HDMI / VGA / TV simultaneous video output
> All channel synchronous realtime playback, GRID interface & smart search
> Support 2 SATA HDD up to 4TB, 2 USB2.0
> Multiple network monitoring: Web viewer, CMS,Mobile phone (Iphone/Smart phone,Andriod,IPAD,Windows phone)



DVR  Parameters:



High Quality  8 Channels Dvr

System
Main Processor Embedded processor
Operating System Embedded LINUX
Video
Input 8 channel, BNC
Standard NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
Audio
Input 8 channel, RCA
Output 1 channel, RCA
Two-way Talk Reuse audio input/output channel 1
Display
Interface 1 HDMI, 1 VGA, 1 TV, BNC(1.0Vp-p, 75)
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
Display Split 1/8
Privacy Masking 8 rectangular zones (each camera)
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Video/Audio Compression H.264 / G.711
Resolution D1/4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120)
Record Rate Main Stream: D1(1~25/30fps)
Extra Stream CIF(1~25/30fps)
Bit Rate 48~4096Kb/s
Record Mode Manual, Schedule(Regular(Continuous), MD), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection& Alarm
Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input 8 channel
Relay Output 1 channel
Playback & Backup
Sync Playback 1/8
Search Mode Time/Date, MD & Exact search (accurate to second)
Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode USB Device / Network
Network
Ethernet RJ-45 port (10/100M)
Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter
Max. User Access 20 users
Smart Phone iPhone, iPad, Android, Windows Phone
Storage
Internal HDD 2 SATA port, up to 4TB
Auxiliary Interface
USB Interface 2 ports (1 Rear), USB2.0
RS485 PTZ control
General
Power Supply DC12V/2A
Power Consumption 10W(without HDD)
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
Dimension(W×D×H) 1U, 324x243x52mm
Weight 2.4KG(without HDD)
