Specifications
8ch 720p realtime hd cvi dvr1080P
8 ch 720p play back
8CH 720P Realtime HD CVI DVR, with HDD up to 3TB
Features
1)8CH 720p Video input realtime& 1CH Audio DVR. P2P function
2)Support D1 resolution, playback CIF real-time
3)Support 8CH simultaneous playback
4)HDMI & VGA support
5)Digital zoom function on both live view and playback mode
6)HDDx1, max 3TB
7)Firmware updatable
8)Multi languages support
DVR information
Model No. |
HCVR-08 |
Video Compression |
H.264 |
OS |
Embedded LINUX |
System Resources |
Multiplex operations: Multiple-channel record, multiple-channel playback and network operation simultaneously |
Interface |
User-friendly graphical user interface |
Input Devices |
Front panel, USB mouse, remote controller |
Video Input |
8-CH Composite Video 1.0Vp-p/75Ω, NTSC/PAL |
Monitor Output |
1-CH Composite Video Output 1.0Vp-p/75Ω, NTSC/PAL |
HDMI Output |
1-CH HDMI, Adjustable resolution: 1920×1080, 1440×900, 1360×768, 1280×720, 1280×1024, 1024×768 |
VGA Output |
1-CH VGA, Adjustable resolution: 1920×1080, 1440×900, 1360×768, 1280×720, 1280×1024, 1024×768 |
Video Standard |
PAL(625line, 50f/s), NTSC(525line, 60f/s) |
Record Speed |
Real-time: PAL 1fps to 25fps per channel and NTSC 1fps to 30fps per channel |
Video Partition |
1/4/8/9 windows |
Recording Mode |
Manual recording, always recording, motion detection recording, schedule recording |
Resolution |
D1:PAL 704*576(200fps) / D1:NTSC 704*480(240fps) |
Playback Resolution |
8ch real-time simultaneous playback(PAL/NTSC): CIF (352×288 200fps / 352×240 240fps) |
Audio Compression |
ADPCM, 16Kbps |
Audio Input |
1-CH 200-2000mv5kΩ, RCA |
Audio Output |
1-CH 200-3000mv1kΩ, RCA |
Network |
RJ45 10M/100M/1000M self-adaptable Ethernet port, support TCP, FTP, PPPOE, 3G, Web browser, CMS, NetViewer |
Mobile OS |
iPhone, Android, Blackberry, Windows mobile, Symbian |
Email for alarm |
Support SMTP server, support SSL |
DDNS |
Build in free privacy DDNS, DYNDNS, 3322, perfect, myq-see and no-ip |
Hard Disk |
Support 1 SATA, max3 TB HDD |
USB Interface |
2 USB 2.0 ports |
Operating Temperature |
+5°~ +50 |
Storage Temperature |
-20°~ +70° |
Humidity |
30 ~95% |
Pictures of product
