Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > Hot Mini 1U 960H HD 4CH DVR Board

Hot Mini 1U 960H HD 4CH DVR Board

Name: Hot Mini 1U 960H HD 4CH DVR Board
Brand: Joney
SKU: 128354841
Availability: InStock

Hot Mini 1U 960H HD 4CH DVR Board thumbnail-1

Hot Mini 1U 960H HD 4CH DVR Board photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Joney

Model Number:

DVR-5004S

Contact Supplier Request Quote Chat Now

Shenzhen Joney Security Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Joney

Model Number DVR-5004S

Specifications

Hot mini 1U 960H 4ch DVR Board
960H realtime
4CH input
Mini 1U
1 HDD up to 3TB

Hot Mini 1U 960H HD 4CH DVR Board

Features of 4CH DVR Board

1)4CH Video input & 1CH Audio DVR. P2P function

2)Support D1 resolution, playback CIF real-time

3)Support 8CH simultaneous playback

4)HDMI & VGA support

5)Digital zoom function on both live view and playback mode

6)HDDx1, max 3TB

7)Firmware updatable

8)Multi languages support

DVR information

Model No.	DVR-5004S
Video Compression	H.264
OS	Embedded LINUX
System Resources	Multiplex operations: Multiple-channel record, multiple-channel playback and network operation simultaneously
Interface	User-friendly graphical user interface
Input Devices	Front panel, USB mouse, remote controller
Video Input	4-CH Composite Video 1.0Vp-p/75Ω, NTSC/PAL
Monitor Output	1-CH Composite Video Output 1.0Vp-p/75Ω, NTSC/PAL
HDMI Output	1-CH HDMI, Adjustable resolution: 1920×1080, 1440×900, 1360×768, 1280×720, 1280×1024, 1024×768
VGA Output	1-CH VGA, Adjustable resolution: 1920×1080, 1440×900, 1360×768, 1280×720, 1280×1024, 1024×768
Video Standard	PAL(625line, 50f/s), NTSC(525line, 60f/s)
Record Speed	Real-time: PAL 1fps to 25fps per channel and NTSC 1fps to 30fps per channel
Video Partition	1/4/8/9 windows
Recording Mode	Manual recording, always recording, motion detection recording, schedule recording
Resolution	D1:PAL 704576(200fps) / D1:NTSC 704480(240fps)
Playback Resolution	4ch real-time simultaneous playback(PAL/NTSC): CIF (352×288 200fps / 352×240 240fps)
Audio Compression	ADPCM, 16Kbps
Audio Input	1-CH 200-2000mv5kΩ, RCA
Audio Output	1-CH 200-3000mv1kΩ, RCA
Network	RJ45 10M/100M/1000M self-adaptable Ethernet port, support TCP, FTP, PPPOE, 3G, Web browser, CMS, NetViewer
Mobile OS	iPhone, Android, Blackberry, Windows mobile, Symbian
Email for alarm	Support SMTP server, support SSL
DDNS	Build in free privacy DDNS, DYNDNS, 3322, perfect, myq-see and no-ip
Hard Disk	Support 1 SATA, max3 TB HDD
USB Interface	2 USB 2.0 ports
Operating Temperature	+5°~ +50
Storage Temperature	-20°~ +70°
Humidity	30 ~95%

Our Service

1. Fast and professional reply within 24 hours.

2. Fast delivery within 5 working days after payment is done.

3. Fast shipment by DHL, Fedex, EMS or other way customers needed.

4. Good performance with 2 years of warranty and lifetime technical support.

5. OEM or customized logo or print is available, and the print fee is free if the order amounts to 50pcs.

6. Promotion price for new customers, more discount for old customers.

7. Special discount and service for our distributor.

8. Convenient multiple way of payment: Paypal, T/T, Western Union.

Our Company

Shenzhen Joney Security Technology Co.,Ltd provide various specification and items of CCTV cameras, PTZ cameras, IP cameras, Standalone DVR, DVR card, related cctv accessories, Fingerprint device, access control system, Alarm products. We have done the business for more than 7 years and now owned over than 1000 models of security products to meet different requirements from our customers.
