China Supplier High Speed Dome 30x CCD Sensor ONVIF Pan Tilt Zoom Camera

Name: China Supplier High Speed Dome 30x CCD Sensor ONVIF Pan Tilt Zoom Camera
Brand: Joney
SKU: 128348771
Availability: InStock

Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Joney

Model Number:

IPC-332

Shenzhen Joney Security Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Joney

Model Number IPC-332

Type Analog Camera

Style Dome Camera

Sensor CCD

Technology Pan / Tilt / Zoom

Special Features Waterproof / Weatherproof

Specifications

--1/4 sony super had ccd
--480/540 tvl
--H.264 compression
--two-way audio
--onvif compliant

china supplier high speed dome 30x CCD sensor ONVIF pan tilt zoom camera

Key Feature:

·1/4 Sony Super Had CCD 480/540 TVL

·22x, 27x, 30xZOOM, from 3.6-97.2mm

·H.264 compression
·Real time transmission up to 30FPS

  ·Interchangeable Lenses Available
  ·Two-way audio supported
  ·Hardware motion detection supported
  ·Wall mount supported

Item		IPC-332
	Device	SONY Super HAD CCD II 480/540TVL
	Size	1/4 inch
	Effective Pixels	D1:640480,CIF: 320240
Min.Scene Illumination	Color	<0.15LUX
	B/W	No
	IR Sensitivity	No
	IR Cut	No
Lens	Lens	22,27,30*ZOOM, from 3.6-97.2mm
	Viewing Angle	Pan:1-300°/s,tilt:1-45°/s(Horizontal)
Linux System		Internal Linux system
Day/Nigh	IR distance
Functions	Motion Detection	Yes
	Electronic Shutter	1/5-1/15,000 sec
	BLC	Yes
	AGC	Auto
	White Balance	Auto
S/N Ratio	S/N Ratio	>50 dB
Video Compression	Compression	H.264
	Picture Resolution	D1:704*576
	Bit Rate	80 K~ 2.0 M bps
	Image Frame Rate	30FPS
Audio	Compression	G.711
	Two way audio	support
Alarm I/O	Alarm I/O	1 channel in/out put
Casing	Mount Types	Wall Bracket
Network	Ethernet	Ethernet (10/100 Base-T),RJ-45 connector
	Protocol	TCP,UDP,IP,HTTP,FTP,SMTP,DHCP,DNS,ARP,ICMP,POP3,NTP,RTP, and RTCP
Software	Web Browser	Microsoft Internet Explorer 6.0 above
	SDK	SDK-H
	Security	Administrator password protection
Operating	Temperature	-30°~60°C
	Humidity	-10~85%
	Power Consumption	<96W (DC 24V,4A)
Physical	Dimension	323247cm
	Weight	6.5kg
Approvals	Certification	CE ,FCC
