20x Zoom 1.3Mp HD Cost-effective Dahua ip Ptz Camera

Name: 20x Zoom 1.3Mp HD Cost-effective Dahua ip Ptz Camera
Brand: Dahua
SKU: 128348511
Availability: InStock

Shenzhen Joney Security Technology Co., Ltd.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Dahua

Model Number:

DH- SD6C120S-HN

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Dahua

Model Number DH- SD6C120S-HN

Type Digital Camera

Style Other, ip ptz camera

Sensor CMOS

Technology Pan / Tilt / Zoom

Special Features Other, IR Distance up to 100m

Specifications

1. ptz ip camera with micro sd memory card
2. 20x optical zoom
3.1.3 Megapixels
4. dual stream
5. 20 online users

Product Description

1.3Mp HD Cost-effective PTZ IP CAMERA

20x optical zoom

H.264 & MJPEG dual-stream encoding

Max. 25/30fps/1.3MP & 720P resolution

DWDR, Day/Night(ICR), Ultra DNR, Auto iris, Auto focus

Multiple network monitoring:Web viewer, CMS(DSS/PSS) & DMSS

Max 300°/s pan speed, 360° endless pan rotation

Up to 255 presets, 5 auto scan, 8 tour, 5 pattern

Built-in 2/1 alarm in/out

Support intelligent 3D positioning with DH-SD protocol

Micro SD memory, IP66

IR Distance up to 100m

Model		DH-SD6C120S-HN
Camera
Image Sensor		1/3” Exmor CMOS
Effective Pixels		1280(H) x 960(V), 1.3 Megapixels
Min. Illumination		Color: 0.05Lux/F1.6, B/W: 0.005Lux/F1.6
Video Output		BNC(1.0Vp-p/75Ω), PAL / NTSC
Camera Features
Max. IR LEDs Length		100m
Backlight Compensation		BLC / HLC / DWDR (Digital WDR)
Digital Zoom		20X
Lens
Focal Length		4.7mm ~ 94mm(20x Optical zoom)
Angle of View		58.9°~ 2.1°
Close Focus Distance		10mm ~ 1200mm
PTZ
Pan/Tilt Range		Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180°
Manual Control Speed		Pan: 0.1° ~160° /s; Tilt: 0.1° ~120° /s
PTZ Mode		5 Pattern, 8 Tour, Auto Pan, Auto Scan
Power up Action		Auto restore to previous PTZ and lens status after power failure
Video
Compression		H.264 / MJPEG
Resolution		1080P(1920×1080) / 720P(1280×720) / D1(704×576/704×480) / CIF(352×288/352×240)
Frame Rate	Main Stream	1080P/720P(1 ~ 25/30fps)
	Sub Stream	D1/CIF(1 ~ 25/30fps)
Audio
Compression		G.711a / G.711u (32kbps) / PCM (128kbps)
Interface		1/1 channel In/Out
Network
Ethernet		RJ-45 (10/100Base-T)
ONVIF		ONVIF Ver. 2.0 conformance
Smart Phone		iPhone, iPad, Android, Windows Phone
Auxiliary Interface
RS485		1
Alarm		7/2 channel In/Out
General
Working Environment		-40ºC ~ 60ºC / Less than 90% RH
Dimensions		Φ204.7(mm) x 359.9(mm)
Weight		7.8kg
