20x Zoom 1.3Mp HD Cost-effective Dahua ip Ptz Camera

20x Zoom 1.3Mp HD Cost-effective Dahua ip Ptz Camera photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Dahua
Model Number:
DH- SD6C120S-HN
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name Dahua
Model Number DH- SD6C120S-HN
Type Digital Camera
Style Other, ip ptz camera
Sensor CMOS
Technology Pan / Tilt / Zoom
Special Features Other, IR Distance up to 100m

Specifications

1. ptz ip camera with micro sd memory card
2. 20x optical zoom
3.1.3 Megapixels
4. dual stream
5. 20 online users


Product Description



1.3Mp HD Cost-effective PTZ IP CAMERA

20x optical zoom
H.264 & MJPEG dual-stream encoding
Max. 25/30fps/1.3MP & 720P resolution
DWDR, Day/Night(ICR), Ultra DNR, Auto iris, Auto focus
Multiple network monitoring:Web viewer, CMS(DSS/PSS) & DMSS
Max 300°/s pan speed, 360° endless pan rotation
Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
Built-in 2/1 alarm in/out
Support intelligent 3D positioning with DH-SD protocol
Micro SD memory, IP66
IR Distance up to 100m

20x zoom 1.3Mp HD Cost-effective Dahua ip ptz camera

Model DH-SD6C120S-HN
Camera
Image Sensor1/3” Exmor CMOS
Effective Pixels1280(H) x 960(V), 1.3 Megapixels
Min. IlluminationColor: 0.05Lux/F1.6, B/W: 0.005Lux/F1.6
Video OutputBNC(1.0Vp-p/75Ω), PAL / NTSC
Camera Features
Max. IR LEDs Length100m
Backlight CompensationBLC / HLC / DWDR (Digital WDR)
Digital Zoom20X
Lens
Focal Length4.7mm ~ 94mm(20x Optical zoom)
Angle of View58.9°~ 2.1°
Close Focus Distance10mm ~ 1200mm
PTZ
Pan/Tilt RangePan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180°
Manual Control SpeedPan: 0.1° ~160° /s; Tilt: 0.1° ~120° /s
PTZ Mode5 Pattern, 8 Tour, Auto Pan, Auto Scan
Power up ActionAuto restore to previous PTZ and lens status after power failure
Video
CompressionH.264 / MJPEG
Resolution1080P(1920×1080) / 720P(1280×720) / D1(704×576/704×480) / CIF(352×288/352×240)
Frame RateMain Stream1080P/720P(1 ~ 25/30fps)
Sub StreamD1/CIF(1 ~ 25/30fps)
Audio
CompressionG.711a / G.711u (32kbps) / PCM (128kbps)
Interface1/1 channel In/Out
Network
EthernetRJ-45 (10/100Base-T)
ONVIFONVIF Ver. 2.0 conformance
Smart PhoneiPhone, iPad, Android, Windows Phone
Auxiliary Interface
RS4851
Alarm7/2 channel In/Out
General
Working Environment-40ºC ~ 60ºC / Less than 90% RH
DimensionsΦ204.7(mm) x 359.9(mm)
Weight7.8kg

20x zoom 1.3Mp HD Cost-effective Dahua ip ptz camera


Packaging & Shipping

20x zoom 1.3Mp HD Cost-effective Dahua ip ptz camera
