Specifications
1.30x optical zoom2.High resolution@650TVL
3. 1/3" Sony CCD
4.IP66 outdoor model
Feature of High Speed Dome Camera
1. support english menu
2. adopt 2 pcs stepping motor
3. rotation speed: Pan:0.6-200 °/s, Tilt:0.8-75 °/s, preset speed: 260°/s
4. support 220 presets, 8 patrol, 4 pattern
5. Automatic identify zoom camera(support SONY/SAMSUNG/HITACHI/HIKVISION/MYTECH/CNB/LG)
6. Pelco-d, Pelco-p, Hikvision, Dahua protocol self-adaptive
7. 2400, 4800, 9600 baud rate self-adaptive
8. 3 level manual speed adjustable(High, middle, low)
9. Memory protection function prevent data from losing when power is suddenly off
10. 2 input/ 1 output alarm ports optional
11. lightning protection
12. Proportional zoom function, rotation speed can be adjusted automatically according to zoom multiples
13. weather-proof protection class: IP66 (outdoor model)
14. power supply: DC 12V(AC 24V optional)
wall/ceiling mount bracket
Specification
| Model | PTZ-A950 | PTZ-B960 |
| Camera | ||
| Image Sensor | 1/3"SONY CCD | |
| Effective Pixels | 640(H) × 480(V) | 752(H) × 582(V) / 768 (H) × 494(V) |
| Horizontal Resolution | 650TVL | 700TVL |
| Scanning System | Progressive | Interlacing |
| Electronic Shutter Speed | 1/50(60)s~1/100,000s | 1/1s ~1/100,000s |
| Min. Illumination | Color:0.5Lux/F1.6 B/W: 0.05Lux/F1.6 |
Color: 0.01 Lux/F1.6 B/W: 0.001Lux/F1.6 |
| S/N Ratio | More than 50dB | |
| Video Output | BNC(1.0Vp-p/75Ω), PAL / NTSC | |
| Camera Features | ||
| Max. IR LEDs Length | 80m | |
| Day/Night | Auto(ICR) / Color / B/W | |
| Backlight Compensation | BLC | BLC / HLC / DWDR (Digital WDR) |
| White Balance | Auto, ATW, Indoor, Outdoor, Manual | |
| Gain Control | Auto / Manual | |
| Noise Reduction | 3D | 3D |
| Privacy Masking | Up to 24 areas | |
| Digital Zoom | N.A. | 16x |
| Lens | ||
| Max Aperture | F1.6~ F3.7 | F1.6~ F3.7 |
| Focus Control | Auto / Manual | |
| Angle of View | H: 53.5° ~2.62° | H: 61.68° ~ 3.06° |
| PTZ | ||
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°, auto flip 180° | |
| Manual Control Speed | Pan: 0.1° ~ 160°/s; Tilt: 0.1° ~120°/s | |
| Preset Speed | Pan: 240°/s; Tilt:200°/s | |
| Preset | 80(DH-SD) , 255(Pelco-P/D) | |
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan, Auto Scan | |
| Power up Action | Auto restore to previous PTZ and lens status after power failure | |
| Time Task | Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time | |
| Protocol | DH-SD, Pelco-P/D (Auto recognition) | |
| Auxiliary Interface | ||
| RS485 | 1 port | |
| General | ||
| Power Supply | AC24V/3A (±10%), DC12V optional | |
| Power Consumption | 13W, 31W (IR on) | |
| Working Environment | -40ºC ~ 60ºC / Less than 90% RH | |
| Ingress Protection | IP66 | |
| Dimensions | Φ185(mm) x 299(mm) | |
| Weight | 5.0kg | |
The other PTZ cameras
