512 DMX Controller/ Lighting Controller

Specifications

 512 DMX controller

model: JL-240A

Technical features
* Up to CE standard,UL standard and  GB 7000.15-2000 standard
* 12 scanners of 16 channels each
* 30 banks have 8 programmable scenes each
* 6 programmable chase have 240 scenes each
* 8 slider for manual control of channels
* 2 assignable wheels for ease of movement
* file dump allows data to be sent for received between 2 units
* auto mode program controlled by speed and fade time sliders
* fade time/assign fade time
* reversible DMX channels fixture to react in opposition to others in a chase
* 8 channel or 16 channel mode
* fine adjustment for Wheel pan and tilt
* blackout master button
* manual override button allow you to grab any fixture on the fly
* built in microphone for music trigerring
* midi control over banks, chases and blackout
* DMX polarity selector
* power failure memory
* fog machine connector
* power input: DC 9-12V 300ma min
* audio input: by built-in microphone or line in, 100mv-1vpp
* DMX in/out: 3 pin male/female XRL
* midi in: 5 pin multiple socket
* Dimensions(mm): 482 x 190 x90
* Net Weight: 3.0kg
* LED lamp connector
* Up to CE standard,UL standard and  GB 7000.15-2000 standard

product photos:
