*Reduces Energy Costs And Consumption*Creates Effective Environmental Separation
*Maintains Interior Building Tempera
Cross Flow A series Air Curtain
Cross Flow A Series maintains environmental separation in a wide variety of industrial and commercial applications.
Designed and built for a wide variety of industrial uses, this kind of model air curtain is a sturdy and durable unit offering reliable performance around the clock. Strong air velocities make it possible to control all types of environments and protect against dust, fumes, flying insects and other unpleasant outdoor elements.
Typical Applications:
·Cross flow air curtain is widely used in public Commercial Entry, Freezer/Cooler Door,Service Door,Shipping/Receiving,airports, railway stations, entrance and exit of subway, gymnasiums, baking finish rooms, textile mills, pharmaceutical factories, electrical appliance factories, automatic doors, etc.
Main Technology Parameters
Model Number |
Voltage/Frequence |
Input power |
Air speed |
Air Volume |
Noise |
Net Weight |
Unit Size |
(W) |
(m/s) |
(m3/h) |
(dB) |
(KG) |
(mm) |
||
FM-A/C(Y)1506 |
220V 50Hz |
80 |
10.0 |
1180 |
59 |
14 |
600×250×260 |
FM-A/C(Y)1509 |
220V 50Hz |
100 |
10.0 |
1440 |
59 |
21 |
900×250×260 |
FM-A/C(Y)1512 |
220V 50Hz |
120 |
10.0 |
1860 |
60 |
31 |
1200×250×260 |
FM-A/C(Y)1515 |
220V 50Hz |
180 |
10.0 |
2230 |
61 |
32 |
1500×250×260 |
FM-A/C(Y)1518 |
220V 50Hz |
250 |
10.0 |
2850 |
61 |
38 |
1800×250×260 |
