Professional Digital Audio Processor

SLAGC1200D series Digital Audio Multi-functional Processor can promptly set audio signals within the preset range via the process of DSP. It has a build-in Digital Gain Controller, which works on digital AES/EBU or analog XLR signals. SLAGC is an effective solution to the unsteadiness of sound volume during ingesting and broadcasting, and transmission unbalance of analog audio signals between different programs.

Support prompt auto gain on digital audio AES3/EBU signal or analog XLR audio signal

Dynamic noise reduction

Build-in digital equalizer, which can shield noise signal according to the present level

With Digital AES3/EBU audio signal I/O interface, or standard XLR stereo balanced or RCA unbalanced audio I/O interface

AGC auto adjust between 20Hz~20 KHz (±0.3dB)

Level enhanced ability over 10dBu on low signal

I/O ratio adjustable

Bypass button for optional on power failure

RS-232 interface optional

Sample Rates: 48K (stereo)

Quantization accuracy: 24bit

SNR: >80dB

Dynamic Range: 96dB

Frequency Response : 20-20KHz ±1dB

Distortion: <0.02%(1dB below clipping@1KHz)

Input impedance: 50KΩ

Output impedance: 100Ω

Interface: XLR

Channels isolation: 90dB

Channels level difference: <0.2dB

Protection: Bypass

Dimension: 480×320×44mm (1U)
