260-33 brass pipe fittings nipple elbow (BRASS FEMALE SWEAT ELBOW 90(F X C) COPPER.)

Specifications

BRASS FEMALE SWEAT ELBOW 90(F X C) COPPER.
CE,ISO9001:2000 Certificate
11 years experience on valv

BRASS FEMALE SWEAT ELBOW 90(F X C) COPPER.



various choices of the surface(lead free)(hot)

-------------------------------------------------------------------------------------------------------------------------------

1. Brass Material

• MS58,MS59

• CW617

• CW602N,CZ132

• Lead free brass



PART	SPECIFICATION
Nut	Steel with plated
Handle	Steel with Chrome or Zinc plating
Stem	Brass ASTM B124-C3700                                 or ASTM B16-C36000
Ball	Brass ASTM B124-C3700                   or ASTM B16-C36000                     with hard Chrome plating
Body & Cap	Brass(ASTM B124-C37700)
Gland	Brass(ASTM B124-C37700)
Seats	Teflon®(PTFE)
Packing	export carton





--------------------------------------------------------------------------------------------------------------------------------------------------------------

2. Size

3/8" , 1/2" , 3/4" , 1" , 1 1/4" , 1 1/2" , 2" , 3" , 4"



Size/   Model	φD	φE	L	C	H(ref)	A(ref)
1/2"	14.8	16.4	53.5	14.5	49.6	90
3/4"	19	22.5	64.5	16	55.3	100
1"	24	30	81.5	19	64	122





-------------------------------------------------------------------------------------------------------------------------------



3. Surface

Yellow brass color

Nickel plated

Chrome plated



--------------------------------------------------------------------------------------------------------------------------------



4.description

nominal pressure: PN≤1.6MPa

Applicable media: water,oil,gas

Thread standard: 55° inch system G pipe thread

Thread: ISO228 ( Equivalent to DIN259 and BS2779) or NPT

Min and Max working temperature : -20<-120°c



----------------------------------------------------------------------------------------------------------------------------------------------------------------



5. Certification

CE, ISO9001:2000



----------------------------------------------------------------------------------------------------------------------------------------------------------------



6. Guaranty

1 Year Guaranty



----------------------------------------------------------------------------------------------------------------------------------------------------------------



7. Features

 1. High quality.

2. Compact and optimized structure.

3. Good price with professional service.

4. Full type of items.

5. Customized service.

6. Prompt delivery time.





----------------------------------------------------------------------------------------------------------------------------------------------------------------



 • Product Photo







 • Certificate





  • Handle for choice



 • Material Options



• Production Environment



  Quality First, Credit Based
