Help CenterStainless Cable Ladder((UL,CUL,CE,SGS,Rohs Test Passed)
Related Products
-
High Quality Channel Strut for BuildingUS$ 5 - 50MOQ: 1 Piece -
EZ Wire Mesh Cable Tray (Manufacturer,UL,CUL,CE,, 10 Years Warranty)US$ 5 - 50MOQ: 1 Piece
-
Cable Roller for Wire Mesh Cable Tray(UL,CUL,CE)US$ 1.3 - 4MOQ: 100 Pieces
-
Cable Roller Manufacturer (UL,CUL,CE)US$ 0.55 - 1.55MOQ: 100 Pieces
-
Stainless Cable Ladder Support (UL,CE Certificated)US$ 5 - 50MOQ: 1 Piece
Specifications
1.ISO9001:2008/UL/CUL/CE,passed Rohs test.2.Have complete accessories.
3. Easy for installation.
Vichnet is professional in manufacturing wire mesh cable tray, The company is located in the beautiful coastal city of Ningbo, Zhejiang Province.
Our wire mish cable tray is windy used by Google ,Cocacola,Siemens ,Mircrosoftect, famous company
Our company has ISO9001:2008 and GMC. Wire mesh cable tray has UL, CUL, CE certificates and passed Rohs, loading capacity, welding strength etc. tests
Our slogan is “Reliable wire mesh cable tray ! Reliable Vichnet!”. At vichnet, we do our best to win the satisfaction of our customers.
Material:
Q235B Steel (Chinese standard steel)
Surface Finish:
Electro zinc plated wire mesh cable tray – for indoor use to BS EN 12329-2000, 12microns thick.
Powder coated wire mesh cable tray- for indoor use to JG/T3045-1998, between 60 and 100 microns thick
Hot Dipped Galvanized wire mesh cable tray – for outdoor use to BS EN 1461-1999, between 60 and 80 microns thick
Electrolytic Polishing wire mesh cable tray – for stainless steel use
| Material | Surface finishing | Thickness of coating | Application environment |
| Q235 Steel | Electro zinc plating | >=12um | Indoor |
| Q235 Steel | Hot dip galvanized | >60um | Indoor, Outdoor |
| Q235 Steel | Powder coating | >60um | Indoor, need colors |
| SS304 | acid washing | N/A | Indoor, Outdoor |
| SS316 | acid washing | N/A | Indoor, Outdoor, high corrosion occasions. |
| SS316L | acid washing | N/A | Indoor, Outdoor, high corrosion |
Dimensions: (Available for customized)
Wire mesh cable tray dimensions are all internal size.
Wire cable basketss are constructed with a 50mm x 100mm, 50mm x 50mm, and 40mm x 40mm mesh grid.
Installation Notice:
Bends, Risers, T Junctions, Crosses and Reducers can be made from perforated cable tray (UL.CUL.SGS.CE) straight sections flexibly in project site.
perforated cable tray (UL.CUL.SGS.CE) should be supported at a normally span 1.5m by trapeze, wall, floor or channel mounting methods (Maxium span is 2.5m).
perforated cable tray (UL.CUL.SGS.CE) can be safely applied in places where the temperature ranges between -40°C and +150°C without any change to their characteristics
Our Advantages
