| HDG specification | |
| Model Number | perforated electrical wire tray |
| Type | UL CUL CE trade assurance perforated electrical wire tray |
| Brand Name | Vichnet |
| Place of Origin | China zhejiang |
| Material | Q235 |
| Surface Finish | Hot dip galvanized |
| Thickness of finishing | >=60μm |
| Color | Zinc |
| Welding Strength Tests | 23+/-2℃,50+/-5%RH |
| Salt Spray Tests | >=720 hour |
| OEM service | Available |
| Certificates | UL ,CUL ,CE, ISO9001,SGS, ROHS |
| Guarantee | 10 years |
| Safe work loading | BS EN 61537:2007 Cable Management Clause 10.4 |
| Port | Ningbo |
| Monthly output | 500K meters |
| Free Sample | Available |
Different type UL CUL CE trade assurance perforated electrical wire trays
and accessories
Product size:
| Item Names | Height | Width | Length | Wire Diameter | Weight | |||
| CM Height-Width-Length-Diameter-Material | mm | inch | mm | inch | mm | inch | mm | kg/each |
| CM25-50-3000-3.5-SS316L | 25 | 1 | 50 | 2 | 3000 | 118 | 3.5 | 0.98 |
| CM50-50-3000-3.8-SS316L | 50 | 2 | 50 | 2 | 3000 | 118 | 3.8 | 1.84 |
| CM50-100-3000-4-SS316L | 50 | 2 | 100 | 4 | 3000 | 118 | 4 | 2.5 |
| CM75-150-3000-4.5-SS316L | 75 | 3 | 150 | 6 | 3000 | 118 | 4.5 | 4.52 |
| CM100-200-3000-4.8-SS316L | 100 | 4 | 200 | 8 | 3000 | 118 | 4.8 | 6.89 |
| CM125-300-3000-5-SS316L | 125 | 5 | 300 | 12 | 3000 | 118 | 5 | 9.37 |
Wire Mesh Cable Tray dimensions are all internal size.
CM100-300-3000-5-Q235:
| Dimensions | |
| Height(H):25mm-150mm... |
|
| Width(W):50mm-1000mm | |
| Length(L):300mm-3000mm | |
| Diameter(D):3.5mm-6.0mm | |
|
Installation Notice: >Bends, Risers, T Junctions, Crosses and Reducers can be made flexible in project site. > It can be safely applied in places. where the temperature ranges between -40℃ and +150℃ without any change to their characteristics. >For security, it can be made available with covers. |
Our certificates:
| Ten Application Area: | |
| 1.data center | 6.sky-in solar energy |
| 2.railway industry | 7.food industry |
| 3.chemical industry and pharmacy | 8.equipment |
| 4.electrical industry | 9.robotics and automation |
| 5.energy production and distribution | nologies-such as wind power |
project reference:
| SEVEN Advantages |
| 1.Vichnet is a leading certificated manufacturer in China. |
| 2.ISO9001:2008/UL/CUL/CE, passed ROHS and SGS tests. |
| 3.Vichnet provides all solution systems, provide the technical guide movie. |
| 4.Advance design team, OEM service accepted. |
| 5.Siemens and GE specified system supplier. |
| 6.Our product loading capacity is 27% stronger than traditional cable trays and cable ladder. |
| 7.Our product makes cables fast heat dispersion and prolong cable life. |
Packing and shipping:
|
Our company Vichnet is a telecommunication product manufacturer specialized in manufacturing UL CUL CE We have a professional team devoted to designing and producing reliable cable tray that meet the needs of our global customers(over 100 countries). Vichnet has approved UL, CUL,CE certificates and passed SGS,ROHS, loading capacity, welding strength etc tests.Our products guarantee 10 years. With GMC and ISO9001 certifications,vichnet becomes a qualified vender that supplies products for Siemens,Google,Microsoft,Coca Cola,IBM,Nsetle,China Telecom and Hua Wei etc. We are trying our best to win the satisfactions from customers. |
Our service:
Welcome to choose our high quality Wire Mesh Cable Tray! More information of our company please view our website:
