Specifications
1.plastic duct and trunk2.easy to install
plete accessories
4.simple maintenance
5.iso9001:2008, sgs, rosh
Fireproof UL94 V0 plastic duct and trunk
Specification: Fireproof UL94 V0 plastic duct and trunk
| Product type | Fireproof UL94 V0 plastic duct and trunk |
| Brand name | Vichnet |
| Country of origin | ZheJiang,China |
| Material | Flame-retardant PVC/ABS |
| Color | Yellow( PANTONE 021U ) |
| Width | 120-240mm |
| Height | 100mm |
| Length | 2000mm |
| Fireproof | GB/T2048-2008 FV-0 |
| Finishing | Smooth |
| Application | IDC, Network, Telecom and device |
| Certificate | ISO9001:2008,SGS,RoHS |
| Warranty | 10 years |
| Monthly output | 50,000meters |
| Nearest port | Ningbo |
| HS Code | 85472000 |
| OEM service | Available |
Fireproof UL94 V0 plastic duct and trunk
Features :
1.Circular design to protect and route optical cable.Fiber outlet,tee and cross
R ≥ 40mm.
2.Cables assemble orderly in network cabinet, ODF and other devices.
3.Easy to assemble.Only tools required are a drill, a screwdriver and a saw.
4.It is manufactured from Flame-retardant materials, the vertical burning test result that fuel goes off within 2 seconds.
5. The system is designed for speed of installation and minimum labour for the installer.
6.The system is extremely adaptable and will evolve to suit demanding market. Currently it is supplied in two sizes. Fireproof UL94 V0 plastic duct and trunk
Fireproof UL94 V0 plastic duct and trunk
| Part Number | Height(mm) | Width(mm) | Length(mm) |
| CF120 (100 X 120) | 100 | 120 | 2000 |
| CF240 (100 X 240) | 100 | 240 | 2000 |
Fireproof UL94 V0 plastic duct and trunk
Fireproof UL94 V0 plastic duct and trunk
Loading Capacity
| CF120 (100 X 120) Loading Capacity | 2mm optic cable | 3mm optic cable |
|
Quantity: 955pcs | Quantity: 424pcs |
|
|
Loading Capacity Quantity: 1433pcs | Quantity: 636pcs |
|
|
Quantity: 1910pcs | Quantity: 848pcs |
Fireproof UL94 V0 plastic duct and trunk
|
CF240 (100 X 240) Loading Capacity |
2mm optic cable | 3mm optic cable |
| |
Quantity: 1910pcs | Quantity: 849pcs |
| |
Quantity: 2866pcs | Quantity: 1273pcs |
| |
Quantity: 3821pcs | Quantity: 1698pcs |
Fireproof UL94 V0 plastic duct and trunk
Table of Contents Fireproof UL94 V0 plastic duct and trunk
| Part name | Description | Parts picture | System Overview |
CF120-CNT CF240-CNT |
Connector | |
|
|
CF120-IRS45 CF240-IRS45 |
Internal Riser 45° | ||
|
CF120-ERS45 CF240-ERS45 |
External Riser 45° | ||
|
CF120-ELB90 CF240-ELB90 |
Horizontal 90°Bend | ||
|
CF120-TEE CF240-TEE |
Horizontal Tee | ||
|
CF120-CRS CF240-CRS |
Horizontal Cross | ||
Fireproof UL94 V0 plastic duct and trunk
| CF240 RDC120 | 240 to 120 Reducer | |
|
| CF240-HTC120 | 240 to 120 Level T | ||
| CF240-VTC120 | 240 to 120 Vertical T | ||
|
CF120-TSP CF240-TSP |
Trumpet Spillout | ||
|
CF120-TTR CF240-TTR |
End Cup | ||
Fireproof UL94 V0 plastic duct and trunk
| CF-OUT |
Movable Cable outlet with tube |
|
|
| CF-OUT-L | Big Movable Fiber Cable Outlet | ||
|
CF120-HGS CF240-HGS |
Braket set | ||
|
CF120-BAR CF240-BAR |
Hanging Bar | ||
| T-Screws L-gasket | Fixings | ||
Fireproof UL94 V0 plastic duct and trunk
Project
Fireproof UL94 V0 plastic duct and trunk
Certificate
Fireproof UL94 V0 plastic duct and trunk
Company introduction
Vichnet is a leading manufacturer of cable management, 8 years experience. Depend on brand building, advanced mechanical equipment, high-quality staff, strict management system, became the approved vendor of British Telecom, Google, China Telecom.With ISO, UL, CE and RoHs certificated, 15 mins reach Ningbo port.This is how we keep good quality and reliable cooperation for gloable valued customers.Our main items are steel wire cable tray,fiber duct system and Aluminium cable tray. Fireproof UL94 V0 plastic duct and trunk
Welcome to choose Vichnet superior quality of fiber runner system,please focus on our website: for more information.
