32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying

32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying thumbnail-1
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying thumbnail-2
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying thumbnail-3
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying thumbnail-4
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying thumbnail-5
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying thumbnail-6
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying photo-1
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying photo-2
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying photo-3
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying photo-4
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying photo-5
32mm and 34mm Tungsten Carbide Taper Drill Button Bit for Stone Quarrying photo-6
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
BESTLINK
Model Number:
BL Series
Contact Supplier Request Quote Chat Now
Xiamen Bestlink Factory Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name BESTLINK
Model Number BL Series
Type Countersink Drill Bit
Material Tungsten Carbide
Use Masonry Drilling

Button bit taper angle/degree: 4° 46, 6° , 7° , 11° , 12°
Socket inside diameter: 19 22 25 28 32 34 36 38 40 42(mm)

OEM and ODM We can design and manufacture according to customers's samples or drawings of the Bit Dia., No. Of air/water holes, carbide button shape and the face shape.

Super Quality Our button bit is made with high quality of best quality alloy steel bar and tungsten carbides, through heat treatment so that it can withstand the toughest rock drilling demands, and transmit intensive impact energy into the rock with the least possible loss of energy.

Global Reputation The taper drill bit is widely used in metallurgy mine, geological exploration, water conservancy construction, electricity, traffic, tunnel, quarry, national defence stone project etc. Our clients
Are all over the world, like Germany, Spain, Italy, Russia, Japan, India, Australia, Mexico, Colombia, Brazil,
Chile, South Africa...Etc. We have very good reputation worldwide!

We can design and manufacture according your sample or drawing.



Drill Bit: Button Bit

For 22 mm ( 7 /8") rod. 4°46' taper. Short skirt.
Diameter (mm) Part No. Length (mm) No. of buttons Buttons x button diameter (Gauge, Centre) Gauge Buttons angle ° (Gauge, Front) Flushing hole (Side, Centre) Weight approx (kg)
36 178-9036-14-67,39-20 50 7 5x7, 2x7 35, - 1, 2 0.3
43 178-9043-14-67,39-20 50 7 5x7, 2x7 35, - 1, 2 0.35

For 22 mm ( 7 /8") rod. 11° taper. Short skirt.
Diameter (mm) Part No. Length (mm) No. of buttons Buttons x button diameter (Gauge, Centre) Gauge Buttons angle ° (Gauge, Front) Flushing hole (Side, Centre) Weight approx (kg)
32 179-9032-12-67,50-20 50 5 3x8, 2x7 35, - 2, 1 0.2
32 179-9032-33-67,39-20 55 8 6x7, 2x7 39, 15 1, 1 0.22
32 179-9032-56-67,50-20 50 6 4x7, 2x7 35, - 1, 1 0.15
33 179-9033-40-67,50-20 60 9 6x7, 3x7 40, 20 2, - 0.2
33 179-9033-56-67,50-20 50 6 4x7, 2x7 40, - 1, 1 0.2
34 179-9034-56-67,50-20 50 6 4x7, 2x7 40, - 1, 1 0.3
35 17990354167-L.39-20* 55 7 5x8, 2x7 40, 15 1, 1 0.3
36 179-9036-12-67,39-20 50 5 3x8, 2x8 40, - 2, 1 0.3
36 179-9036-23-67,50-20 50 4 3x9, 1x8 35, - 1, 1 0.2
36 179-9036-27-67,39-20 50 7 5x8, 2x7 35, - 1, 1 0.3
36 179-9036-56-67,50-20 50 6 4x7, 2x7 40, - 1, 1 0.35
38 179-9038-23-67,39-20 50 4 3x9, 1x9 40, - 1, 1 0,35
38 179-9038-27-67,39-20 50 7 5x9, 2x7 35, - 1, 1 0.35
40 179-9040-12-67,39-20 50 5 3x9, 2x9 40, - 2, 1 0.35
40 179-9040-23-67,39-20 50 4 3x9, 1x9 40, - 1, 1 0.35
41 179-9041-27-67,39-20 50 7 5x9, 2x7 35, - 2, 1 0.35

For 22 mm ( 7 /8") rod. 12° taper. Short skirt.
Diameter (mm) Part No. Length (mm) No. of buttons Buttons x button diameter (Gauge, Centre) Gauge Buttons angle ° (Gauge, Front) Flushing hole (Side, Centre) Weight approx (kg)
27 177-9027-56-67,39-20 50 6 4x6, 2x6 40, 15 1, 1 0.2
28 177-9028-23-67,39-20 50 4 3x7, 1x7 20 1, 1 0.2
29 177-9029-23-67,39-20 50 4 3x7, 1x7 40 1, 1 0.2
30 177-9030-23-67,39-20 50 4 3x7, 1x7 40 1, 1 0.2
30 177-9030-56-67,50-20 50 6 4x7, 2x7 30 1, 1 0.2
32 177-9032-14-67,39-20 50 7 5x7, 2x7 35 1, 2 0.2
32 177-9032-17-67,39-20 50 7 5x7, 2x7 35 1, 1 0.2
32 177-9032-34-67,39-20 50 8 6x7, 2x7 39, 15 1, 2 0.2
33 177-9033-14-67,39-20 50 7 5x7, 2x7 35 1, 2 0.2
33 177-9033-17-67,39-20 50 7 5x7, 2x7 35 1, 1 0.2
33 177-9033-41-67,39-20 55 7 5x8, 2x7 40, 15 1, 1 0.2
33 17790334167-L.39-20* 55 7 5x8, 2x7 40, 15 1, 1 0.2
34 177-9034-17-67,39-20 50 7 5x8, 2x7 35 1, 1 0.22
35 177-9035-27-67,39-20 50 7 5x9, 2x7 35 1, 1 0.22
35 177-9035-56-67,50-20 50 6 4x7, 2x7 35 1, 1 0.22
36 177-9036-27-67,39-20 50 7 5x9, 2x7 35 1, 1 0.3
37 177-9037-27-67,39-20 50 7 5x9, 2x7 40 1, 1 0.3
38 177-9038-23-67,39-20 50 4 3x9, 1x9 40 1, 1 0.2
38 177-9038-27,39-20 50 7 5x9, 2x7 35 1, 1 0.25
38 177-9038-27-67,39-20 50 7 5x9, 2x7 35 1, 1 0.25
41 177-9041-27-67,39-20 50 7 5x9, 2x7 35 1, 1 0.35
-67 = ballistic buttons *
Long bit head

For 22 mm ( 7 /8") rod. 7° taper. Long skirt.
Diameter (mm) Part No. Length (mm) No. of buttons Buttons x button diameter (Gauge, Centre) Gauge Buttons angle ° (Gauge, Front) Flushing hole (Side, Centre) Weight approx (kg)
32 173-5032-17,39-20 80 7 5x7, 2x7 35, - 1, 1 0.3
32 173-5032-17-67,39-20 80 7 5x7, 2x7 35, - 1, 1 0.3
33 173-5033-17-67,39-20 80 7 5x7, 2x7 35, - 1, 1 0.3
35 173-5035-27,39-20 80 7 5x8, 2x7 35, - 1, 1 0.33
35 173-5035-41,39-20 80 7 5x9, 2x7 25, 15 1, 1 0.33

For 22 mm ( 7 /8") rod. 12° taper. Long skirt.
Diameter (mm) Part No. Length (mm) No. of buttons Buttons x button diameter (Gauge, Centre) Gauge Buttons angle ° (Gauge, Front) Flushing hole (Side, Centre) Weight approx (kg)
32 177-5032-17-67,39-20 71 7 5x7, 2x7 35, - 1, 1 0.3
33 177-5033-17-67,39-20 71 7 5x7, 2x7 35, - 1, 1 0.3
33 177-5033-34-67,39-20 71 8 6x7, 2x7 40, - 1, 2 0.3
33 177-5033-40-67,39-20 71 9 6x7, 3x7 40, 20 3, - 0.28
35 177-5035-34-67,39-20 71 8 6x8, 2x7 39, 15 1, 2 0.3

For 25 mm (1") rod. 12° taper. Long skirt.
Diameter (mm) Part No. Length (mm) No. of buttons Buttons x button diameter (Gauge, Centre) Gauge Buttons angle ° (Gauge, Front) Flushing hole (Side, Centre) Weight approx (kg)
35 180-5038-27-67,39-20 71 7 5x9, 2x7 35, - 1, 1 0.38
38 180-5041-27-67,39-20 71 7 5x9, 2x7 35, - 1, 1 0.38
