4.5Kw Softgel Encapsulation Machine By Vegetable Oil
US$ 1 - 110,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Capacity:
50000-70000pcs/hour
Control Mode:
Full Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CE Certificated Fully Automatic Small- Scale Paintball Making Machine SaleUS$ 1 - 65,000MOQ: 1 Set -
Die Roll for Paintball Pellet Making Machine For Camping Event S610PBUS$ 1 - 200,000MOQ: 1 Set
-
Smile Print Full Automatic Paintball Making Machine LineUS$ 1 - 200,000MOQ: 1 Set
-
CS Grade Gelatin Shell R&D Scale Paintball Makiing Machine S403PBUS$ 1 - 200,000MOQ: 1 Set
-
Tournament Grade 0.68" Painball for CS Games Factory and Encapsulation MachineUS$ 16 - 16MOQ: 1600 Boxes
Condition
New
Capacity
50000-70000pcs/hour
Control Mode
Full Automatic
Place of Origin
Beijing, China
Brand Name
kunyou
Model Number
S407
Dimension(L*W*H)
800*2200*2000mm
Weight
1200kg
Certification
CE ISO9001
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
S407 automatic soft capsule encapsulation machine is developed based on Model S406 softgel encapsultation machine.
The die roll length is 20mm longer.
Material of oil roller : porous stainless steel
Micro gelatin ribbon oil lubrication
Precision temperature control for injection wedge,spreader box and chilled water
The running parameters can be stored and recalled with a finger tip touch if necessary
Pneumatic wedge lift up
Pneumatic left die shaft movement
Specification
Model |
S407 |
Die roll size |
Φ130×Φ172mm |
Die roll speed |
0~7 rpm |
Plunger number |
12 |
Overall dimension |
880×2200×2000mm |
Weight |
1200kg |
Power |
4.5kw |
Control model |
PLC+Touch Screen |
Output |
8#OA50,000-70,000pcs/hour |
Dosage deviation |
≤2% |
Parallel degree of main shaft of the die rolls |
<0.02mm |
