New Design Machine To Make Paintball
US$ 1 - 200,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Capacity:
115,440PCS/HOUR, 2000capsules/min
Control Mode:
Full Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN XINGANG
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Efficient Large Scale Paintball Encapsulation Production Line S610PBUS$ 1 - 200,000MOQ: 1 Set -
Paintball Machine For Tournament Grade PaintballUS$ 1 - 95,000MOQ: 1 Set
-
CE Certificated Automatic Small Scale Paintball Production Line Paintball MachineUS$ 1 - 200,000MOQ: 1 Set
-
Medium Scale Paintball Making Machine SaleUS$ 1 - 110,000MOQ: 1 Set
-
Paintball Making Machine ( Soft Capsule Machine)US$ 1 - 200,000MOQ: 1 Set
Condition
New
Capacity
115,440PCS/HOUR, 2000capsules/min
Control Mode
Full Automatic
Place of Origin
Beijing, China
Brand Name
KUNYOU
Model Number
S610
Dimension(L*W*H)
2050*1200*1850mm
Weight
1900kg
Certification
CE ISO9001
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
New Design Machine To Make Paintball
Pump Type |
20/24 Plungers |
Driven Type |
Electric |
Capacity |
120000pcs /hour, 8#OV |
Dosage deviation |
<±1.5% |
Application |
Medical,Food, Pharmaceutical |
Control |
PLC |
Product Description
KUN YOU S610 fully automatic softgel making machine is a new generation of soft gelatin encapsulation machine. The machine is integrated the latest global encapsulation technology and our gelatin encapsulation experience. The new softgel encapsulation manufacturing facility features leading technology, simple but beautiful appearance. Advanced technology and reliable performance provide high effective operation and save user's operational cost. S610 softgel encapsulation machine has a high production rate. It can produce about 120000 pcs softgels per hour.
Characteristics
1. Computer control the plunger pump, improve the precision of medicine injection volume, and save more medicine and material cost.
2. Bigger cam drive plunger pump, can provide stronger to plunger pump. That make the machine can inject widely high viscosity of raw material, such as Suspension, Propolis (Bee glue), Soft phospholipids, Liquid calcium and Herbal suspension.
3. Friendly human-computer interface, easy to operated. The simulated running of machine. The data can be set via touch screem, and easy to realizes network monitoring, statistics and reports output.
4. High quality and intelligence control system, PLC true color touch screen technology adopted by the electronic control system. All electric parts use world brand parts, such as Siemens, Schneider
5. Speed of each gelatin film drum and main axis can be adjusted respectively by respectively invertor; that is controlled by operator according to actually requirement.
6. The opening of gelatin box is controlled accurately, the gauge showed gelatin film thickness. Easy to control the thickness.
7. Automatic controlled water-cooling system is adopted for the cooling of gelatin film, which is more safety and more reliable.
8. Air-cooling system is adopted at the output of softgelcapsule, that make softgel capsule more beautiful.
9. Insulation hopper, can keep medicine temperature steady, more suit to fill suspension into the softgel capsules.
Specification
Model |
S610 |
Die roll size |
150×250mm |
Die roll speed |
0~5rpm |
Max plunging volume per stroke |
0~2ml |
Plunger numbers |
20/24 |
Overall dimension |
2050×1200×1850 |
Weight of main machine |
1900kg |
Power consumption |
20 kw |
Control mode |
PLC+Touch Screen |
output |
8#OV115,440 pcs/hour |
Advantages
1. Full automatic.
2. Siemens constrol system.
3. Precisional machine & Hi-steady.
4. Best machine from China.
5. Conforming to GMP.
Automatic Softgel Making Machine, Soft capsule Encapsulation Machine, Paintball Encapsulation Machine
