Krill Oil Softgel Encapsulation Machine
Product Description
S406 Propolis Soft Capsule Making Machine considers the need and the biggest benefits of customers as start point, combining advantages of foreign equipment and requirements of customers. S406 Softgel Encapsulation Machine’s die roll is 152 mm long. The die roll’s rotation rate can be regulated within 0 to 5 rpm, so users can choose the most appropriate speed according to different materials and process parameters.
S406 Softgel Encapsulation Machine improves the bearing spindle supporting way of die roll, thus making the spindle more accuracy and much easier to repair.
In addition, the machine further improves the machining precision. More helical gears are used in the process of gear moving, which improve the gear coincidence degree and transmission stability. The spilt structure of cooling fan reduces the thermal effect to the pressure pill. Besides, gelatin barrel is added with wheel which can be moved more conveniently and easily.
The machine is provided with stirring or insulation optional hopper, using ground automatic feeding method. The soft capsule machine’s oil roller is made of stainless steel material, so it’s more in line with the requirements of GMP.
Specification
Model |
S406 |
Die roll diameter |
Ø103mm |
Die roll length |
152mm |
Die roll speed |
0~5rpm |
Plunger numbers |
10 |
Dosage tolerance |
± 2% |
dimension |
880X640X1900mm |
weight |
900kg |
Power consumption |
2.75kw |
Control mode |
PLC+HMI Switch/buttons |
Output rate |
8#OV 43470 pcs/hour@4rpm |
Competitive Advantages
1. Good stability
2. Adjustable rotation rate during 0-5rpm
3. Easy to operate and clean, conforming to GMP
4. Compact and beautiful
5. It can be assembled or disassembled with single hand
