304 SUS Gelatin Melting Tank / Three Layers Of Water Bath Heating / 450L
US$ 1 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Control Mode:
Full Automatic
Place of Origin:
Beijing, China
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Gelatin Service Tank For Gelatin Making MachineUS$ 1 - 100,000MOQ: 1 Set -
Water Bathed Gelatin MelterUS$ 1 - 100,000MOQ: 1 Set
-
600L Softgel Gelatin Melting Tank With Vacuum Design / Stirring FunctionUS$ 1 - 10,000MOQ: 1 Set
-
Automatic Gelatin Service Tank For Gelatinous Production LineUS$ 1 - 100,000MOQ: 1 Set
-
Water Bathed Softgel Preparation Machine For Softgel Encapsulation Making MachineUS$ 1 - 10,000MOQ: 1 Set
Condition
New
Control Mode
Full Automatic
Place of Origin
Beijing, China
Certification
ISO:9001
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
304 SUS Gelatin Melting Tank / Three Layers Of Water Bath Heating / 450L
Quick Detail
Product Name |
Gelatin Melting Tank |
Heating type |
Water-bath heating |
Application |
Paintball /Soft capsule manufacturers |
Model |
450L |
Material |
304 SUS/316SUS |
Capacity |
650L |
| Inspection Hole | can be as your requirement | Mixter | bottom/top |
Product Description
The Series of gelatin reactor is the essential equipment in gelatin preparation.
The Capacity is from 450L, to 1000L
Main technical data
Vacuum degree in the vessel: 0.02-0.09 Mpa.
Working pressure in the vessel: 0.03-0.05 Mpa.
Examining Pressure in the vessel: 0.Gelatin Melting Tan3-0.4 Mpa.
Working pressure in the jacket: 0.03-0.098 Mpa
Working temperature in tank: 50-100 °C
Conveyor granule: 30 CP
Sealing parts and ring can used more than 3,000 hours continuously.
Insulating layer use super-fine glass cotton.
Inner vessel and insulation layer (covered layer) of the Tank, those sections exposed to raw material are made of 1Cr18Ni9Ti stainless steel.
Application
It’s mainly for softgel making and paintball making enterprises. Besides, the cosmetic manufacturer also needs this to make cosmetics, such as bath beads. And health products manufacturers also need this to make different softgels for the different needs.
Specification
Model |
450L |
Capacity(L) |
650 |
Melting gelatin(L) |
100-450 |
Heating area(M2) |
3.2 |
Max degree of Vacuum(Mpa) |
0.09 |
Max Temperature(℃) |
-100 |
Motor Power (KW) |
4 |
Stirring speed (r/min) |
50 |
Dimension (mm) |
Φ1210X1880 |
Competitive Advantage
1. Stainless steel construction, multi-layer stirrer.
2. Soft capsule /painball gelatin melting tank, heated by circulated hot water.
3. Water sealed vacuum pump is adopted.
4. Designed with three stainless steel interlayer it, helps for accurate control of the temperature of medicine liquid.
5. Typically designed paddle ensure agitating quickly and mixing uniformly.
6.It’s convenient in installation and cleaning.
