Gasoline rock drill
The Internal Combustion Rock Drill Type YN27 J is a very efficient machine with the characters of the structure is very compact, less of the- easy-to-damage-parts, and very easy to control. It can adapt to these outside situations there is no water and electronic power. It is a kind hand held drill built up with gasoline engine, air pump, rock drill and the rotation plumbum equipment for running or stop. It can be used as a tool for breaking, percussive drilling, tamping besides rock drilling.
Gasoline rock drill
The Internal Combustion Rock Drill Type YN27 J is a very efficient machine with the characters of the structure is very compact, less of the- easy-to-damage-parts, and very easy to control. It can adapt to these outside situations there is no water and electronic power. It is a kind hand held drill built up with gasoline engine, air pump, rock drill and the rotation plumbum equipment for running or stop. It can be used as a tool for breaking, percussive drilling, tamping besides rock drilling.
Technical specifications | |
Weight of main machine |
27kg |
Overall dimensions(L*W*H) |
746*315*229mm |
Type of engine |
Single cylinder, air cooled two strokes |
Cylinder diameter*stroke of piston |
D=58*70mm |
Rotation speed of engine |
≥2450rpm |
Displacement of engine piston |
185cm³ |
Type of carburetor |
hand needle valve, floatless type |
Ignition system |
controllable silicon, contactless system |
Drilling speed (mean value of five holes) |
≥250mm/min |
Drilling hole diameter |
D=28-42mm |
Max drilling depth |
6m |
Fuel consumption |
≤0.12L/m |
Tank capacity |
≥1.5liter |
Mixture ratio of gasoline and lubrication oil (in volumes) |
12:01 |
Drill rod and breaker shank |
Hex22*108mm |
Rotating speed of drill rod |
≥200rounds/min |
Clearance of spark plug |
0.5-0.7mm |
