Help CenterMatrix Body Pdc Drill Bits,PDC Rock Bit,6.5 Inch ,pdc Bits & Well Drilling PDC Bits
Related Products
-
5 7/8 " PDC Diamond Bits,/diamond BitsUS$ 200 - 3,000MOQ: 1 Piece -
24 Inch IADC537G Tricone Bit for MineUS$ 200 - 3,500MOQ: 1 Piece
-
5" Hard Rock PDC Drill Bit/ Diamond Drilling Bit for Oilfield DrillingUS$ 300 - 5,000MOQ: 1 Piece
-
Petroleum Drill Bits 5 7/8" PDC BitsUS$ 300 - 5,000MOQ: 1 Piece
-
PDC Drill BitUS$ 1,000 - 5,000MOQ: 1 Piece
Formation | Lithology | IADC |
Very soft | Clay | M121 |
Mudstone | M222 | |
Marl | M222 | |
soft | Marl | M223 |
Rock salt | M232 | |
Gypsum | M232 | |
Sandstone | M232 | |
Medium | Shale | M322 |
Sandstone | M322 | |
Cretaceous | M323 | |
Medium | Shale | M323 |
Mudstone | M323 | |
Sandstone | M323 | |
Limestone | M323 | |
Medium | Shale | M422 |
Mudstone | M333 | |
Sandstone | M422 | |
Limestone | M423 | |
Anhydrites | M432 | |
hard | Dolomite | M432 |
Siltstone | M433 | |
Limestone | M433 | |
Dolomite | M433 | |
Quartzite |
| |
Very hard | Quartzite |
|
Basalt |
| |
Flint |
|
1. Cutting structure is force balanced and bit blade is asymmetrically designed so that the load on bit is balanced that
resulting better stability of the bit.
2. Main cutter are high performance PDC cutters to insure service life of the bit while improving ROP.
3. Cutter exposure is optimized to insure the bit can achieve higher ROP is soft to medium formations.
4. Shock absorbers are designed to make the bit capable of drilling through formations with hard strigers.
5. Hydraulic system of the bit is optimized using dynamic flow pattern simulation technology to enhance cleaning and
cooling effects of the bit to effectively prevent bit from balling.
1,Suit for drilling medium to medium-hard formations.
2,Evolute asymmetrical blade cutter design and balanced bit load so that bit whirl is prevented.
3,Composite gage protection and low torque design improve rate of penetration.
4,CFD hydraulic balance design results in better bit cleaning and cutting removal .
5,Combined utilization of high performance PDC compacts significantly prolongs bit life
6,Higher nozzle counts and/or fixed ports to best serve cleaning,cooling and cuttings evacuation requirements with available hydraulic flows.Allows for higher flow rates with minimal increase in pump pressure.
Above all:
Feature:Diamonds are impregnated in the matrix behind the PDC cutters
Benefit:Increased footage drilled in abrasive applications.
