3M adhesive kapton flexible heating film
Polyimide is a thin, lightweight organic polymer film which provides excellent tensile strength, tear resistance and dimensional stability. The polyimide heater is ideal for applications requiring low outgassing in a vacuum, or resistance to radiation, fungus and chemicals.
Applications:
- Medical applications that require a clean, sterile environment
- Laboratory research
- Semiconductor processing equipment
- Optical equipment
- LCD displays
- Computer equipment
- Photographic equipment
- Aerospace/defense, where low outgassing properties are required
-Etched foil provides options for variable watt density and complex heat patterns.
- Etching circuits is an efficient means for manufacturing in high quantities.
- Foil thickness ranges from .0005″ to .004″ depending on your required resistance.
- Different foil material types can be used depending on the heater resistance needed.
- Etched designs are excellent for applications requiring watt densities greater than 5 watts/in2.
- Excellent choice for heaters that require multi-zoned wattages or heaters that have many holes or cutouts.
- Offers excellent circuit repeatability.
- Elimination of edge loss due to compensation using distributed wattage.
Company certification: ISO9001:2008, ISO 14001
Product certifcation: UL, CUL, CE
