PVC Wood Plastic Foamed Plate Extrusion Line

Specifications

1.adopts the special technology
2.stable working, reliable, good haul-off strength

Introduction

PVC Wide Wood Plastic Foamed Plate Extrusion Machine Line
XD Series PVC Wide Wood Plastic Foamed Plate Extrusion Line is mainly used for producing building moulding plate, wide door plate, cupboard plate, decorative materials indoors or outdoors. According to the different board section, the guest could choose different extruders, like parallel extruder or conical twin-screw extruder. And meanwhile, the other parts of the production line, like vacuum shaping and forming table, haul-off, transverse saw cutter, stacks could be selected according to the different extruder. The capacity of the main extruder is optional from 250kgs to 800kgs. The haul-off adopts the special up-down technology of our company, which leads the advantages of stable working, reliable, good haul-off strength. The vacuum shaping and forming table adopts special-designed enlargement vortex cooling system to meet the need of cooling the plate. The lateral direction saw cutter keeps synchronous with the haul-off machine by imported PLC controller, and it could assemble the swarf suction.

Technical parameters

Items Specifications	XD400	XD600	XD900	XD1200
Max. Width of Plate (mm)	400	600	900	1200
Haul-off Height (mm)	150	150	150	150
Haul-off Force (kn)	20	30	40	50
Haul-off Speed (m/s)	0-3	0-3	0-2.5	0-2.5
Auxiliary Total Power (kw)	30	30	40	45
Cooling Water Capacity (m3 /h)	6	9	12	15
Pressure of Compressive Air (mpa)	0.6	0.6	0.6	0.6
