multicolor DMX chasing Running LED Digital tube light CE RoHS

Specifications

1,direct from DMX Digital led program tube light
3,TM1812 IC with 5050 SMD RGB
4,DMX and Madrix software magic tube
5,CE ROHS



Advantages:



1, direct from Factory led digital tube DMX Control and compatile Madrix software light



2, 48pcs SMD LED tube 5050 light



3, IC TM1812



4, DC12V voltage



5, DMX controller and compatible Madrix software







Introduction







1, ADS-5044 is a combination of a aluminium shell and PCB board,
also 4 spell line with blue,green,yellow,red color.with 48 PCS 5050 RGB LED with 4 pcs TM1812 IC



2,This product can achieve effects of full-color running water,chasing and scanning. depending on the different installation
methods may compose different dynamic effect of different color's character and design.



Easy installation, high brightness, safe and energy conservation, long lifespan,Low brightness declines.Widely used in
building profile, Street lighting,stage view,outside Ads screen, entertainment and so on for decoration and lighting.





  Specification

 ADS-603 module parameter

Items	color	wavelength	LED Qty	SMD	dimension	Lumen	Unite
ADS-5044	Red	619-636K	48	5050 SMD	1000*50*62	158.5	1meter
	Green	512-528K				480
	Blue	463-475K				129.5

 Parameter:

Items	Parameter	Units
Voltage	DC12V	V
Power	12	W
Temperature	-40-60	°C
IP grage	IP66
demension	1000*50*62	mm
Lifespan	50 000	hours
View angle	120	degree





IP66 RGB LED 12w digital tube/LED hurdle light







1 Model:ADS-5044



 2.Aluminium alloy cover+frosted(transparent) PC shell



3.DC12vV
4. Red, yellow ,blue ,white,green and magic rgb color lighting effect



 5.50000hrs lifespan



 6.CE rOHS approval



7.Two year warranty



8.OEM service with competitive price







LED digital tube, adopts the high bright SMD 5050 as the light source and the modern advanced illuminant technology in the world, uses advanced micro-electronics and numeral technology, has features of lower supply, hign luminance, long longevity and so on.







DMX512 or SD Card controller digital tube is an RGB tube light suitable for indoor and outdoor decorative applications.







LED digital tube are easily to be organized into an analog LED display which can provide various full-color effects and dynamic display image characters. Offline control may be used or synchronous control can be used by connecting to computer. It can display diversified full-color dynamic effects. Utilizing this design, displaying image and playing animations on buildings outfaces are just as easy as copying the image files generated into a CF card. The digital tube can be separately controlled or under interlinked control.











Product Applications



1) Mood lighting for municipal roadways,streets,bridges,housing projects and public parks



2) Indoor and outdoor decoration lighting



3) Architectural decorative lighting



4) Emergency and security lighitng



5) Backlighting for signage letter



6) Window display lighting



7) Channel letter lighting



8) Path&Contour marking



9) Under-cabinet lightis







DMX



The digital tubes can be installed and arrayed at your will, suitable to complicated engineering needs.  The digital tube, controller and power are connected by standard male plug, easy and quick.  The appearance design is unique, followed by the latest outdoor waterproof structure. It is widely applied to curtain wall of the building, decorative lighting of recreational sights and highlighting of bridges .







DMX512 digital tube is an RGB tube light itable for indoor and outdoor applications, it is a ideal choice for linear lighting and building decorations. Compatible with universal DMX512 protocol standard, which can be controlled by any DMX devices; Each tube can be divided into 1, 2, 6, 8, or 16 pixels as per typical requirements, introducing an eye-catching new element to the designer's toolbox for optical effects.







Widely used for lighting enhancement among areas such as building exterior, bridge, plaza, stage, shopping mall, hotel or casino etc
