Home > Products > LED Ceiling Light > 7W Voltage AC 85-265V LED Ceiling Lamp for Room
7W Voltage AC 85-265V LED Ceiling Lamp for Room
- 10000 Piece / Pieces per Month
- shenzhen
- Credit Card
- Linear Downlight
- LED Downlight
- A Anti-glare Waterproof IP65 led downlight project waterproof spots light 5w 7w 9w 12w downlight
- A Surface Mounted Led Downlight AC LED Bulb Outdoor Adjustable Led Downlight Lamp Spot Light
- Dimmable IP65 LED Down Lights (30-300W)
- Emergency IP65 LED Down Lights (30-300W)
Product Details
LED Light Source: | 1W LED | Warranty(Years): | 2 | Input Voltage(V): | AC85-265V |
Lamp Power(W): | 7 | Lamp Luminous Flux(lm): | 700 | Lamp Luminous Efficiency(lm/w): | 100 |
Color Temperature(CCT): | Cool White | Working Temperature(℃): | -40, 60 | Working Lifetime(Hour): | 50000 |
Lamp Body Material: | Aluminum Alloy | IP Rating: | IP44 | Certification: | CE |
Model Number: | ADS-THW-7B | Place of Origin: | Guangdong, China | Brand Name: | ADS |
Product Description
Specifications
1. Led Ceiling Lamp2.Epistar 7pcs high power 1W led
3.Factory in shenzhen
4. 700lumen
5.CE,RoHS
Led Ceiling Lamp
Epistar 7W 35mil leds
Factory in shenzhen
Aluminum with Milky white cover.
high lumen 700
Product Information
Input voltage | AC85-265V, 50~60Hz |
LED Type | Epistar 35mil |
LED Qty | 7pcs |
LED Power | 7W |
Lumens | 700±5% |
Color Temp | 2700-7000K |
CRI | Ra>80 |
Life-span | >50,000hrs |
Beam Angle | ≥120° |
Total Harmonic Distortion | ≤15% |
Power Factor | >0.88 |
Working Temp | -25°C~+50°C |
Storage Temp | -40°C~+80°C |
Outer shell material | A1uminum + Milky white cover |
Color of the Lamp | Silver |
Certification | CE / RoHS |
Lamp Weight G.W./N.W | 0.306Kg/Pcs |
Dimension | Φ101*65.5mm |
Features And Application
1. energy saving and environmental protection, does not contain lead , mercury and other harmful substances ;
2. Long Lifespan, over 50,000hrs.
3. safe and reliable, impact resistance, anti - Lei Lijiang ,no ultraviolet and infrared under working in low thermal voltage
4. High brightness, no flicker, eliminating the traditional strobe light visual fatigue ;
5. Wide voltage range over the global. Life and brightness from voltage fluctuations ;
6. fast response. No flashing when start like traditional light. Which means lighting when starts
7. Application: shopping malls, office buildings, hotels, Show Rooms, conference rooms, hospitals , window, bedroom and other places, particularly suitable for decorative lighting of the ligh standards of luxury space.
LED Ceiling Light Feature
1. Energy Saving. Saving around 70% electricity cost to traditional Lightings.
2. Advanced super longlife and stable driver.
3. Professional thermal management.
4. Instant on, no warm up time required.
5. No noise, no flickering.
6. No UV or IR radiation in the beam, mercury free.
7. Anti-shock, anti-moisture.
8. Exquisite small appearance. Easy to install with mounting brackets.
9. Eco-friendly. No mercury and other harmful materials
10. No delay on start.
11. Long life span, longer than 50,000~60,000H
Applications
*Office lighting,Artwork lighting,Display case
*Home lighting
*Commercial lighting,such as supermarket,shopping mall,etc...
*Hotel,Restaurant lighting
*Public lighting
Closet illumination
Cove lighting
Cubicle, workbench lighting
Product Structure
Product installation
Installation Steps
1,Lock the Aluminum plate in heat lamp cup with a screw
2,fix the Outer aluminum trap with screws
3,Lock the Crystal lampshade into the heat lamp cup with screw
4,install the Buckle.
Installation Notes
1,before installation pls check whether the bulb is with poor appearance and damage deformation, if with problems pls don’t use.
2,make sure the switch is in the off state when install , be safety
3,Do not disassemble this product if Non - Professionals
4,Only can be used when work properly reference to the instruction..
Luminous Intensity Distribution Diagram
Projects Picture
