Help Center200,000kcal Heat Value Fast Heating Two(2) Stages Gas Burner, Hot Air Convection Burner for Powder Paint Coating Curing Oven
Related Products
-
400,000kcal Heat Value Fast Heating 2 (two) Stage Gas Burner, Air Convectional Industrial Burner for Paint Coating Curing OvenUS$ 2,500 - 3,600MOQ: 3 Sets -
100,000kcal Heat Value Fast Heating 2 (two) Stage Hot Air Gas Burner, Industrial Air Convectional Burner for Powder Coating PlanUS$ 2,000 - 3,000MOQ: 3 Sets
-
500,000kcal Heat Capacity Fast Heating 2 (two) Stage Air Convectional Gas Burner, Automatic Industrial Air Burner for Paint CoatUS$ 3,000 - 4,000MOQ: 2 Sets
-
600,000kcal Fast Temperature Rising 2 (two) Stage Hot Air Conventional Industrial Gas Burner for Gas Steam BoilerUS$ 3,200 - 4,500MOQ: 2 Sets
-
340kw Heat Output Fast Baking Two Stage LPG&NG Burner for Power Coating Industry, Gas Steam Boiler Hot Air Convection BurnerUS$ 2,500 - 3,500MOQ: 3 Sets
Specifications:
1. 200000kcal Eclipse(USA) burner head
2. 3/4" Honeywell gas solenoid valve or Chinese brand solenoid valve
3. 3/4" normal fire honeywell gas solenoid valve or chinese made solenoid valve
4. 1/4" pilot fire honeywell solenoid valve or chinese brand
5. Japan Yamatake gas pressure detector
6. Japan Yamatake air pressure detector
7. 200000kcal burner blower
8. LV4403B66 gas regulator
9. LC-105 ignition controller
10. electric panel
11. 0-1500mm low pressure meter
12. BKC temperature controller
1. Safe and Reliable automatic program control:
Automatic program run control, and fully monitor the combustion condition, safe and reliable control method;
By setting control parameters such as temperature or pressure can set automatic start/stop convenient and easy control.
Configuration with the function of safety switch and flow control of gas safety solenoid valve, to ensure the safety gas supply and cut off;
by using ion induced flame monitoring device to realize flame-out protection function and ensure the security and stability of flame;
Configuration of gas pressure and air pressure safety protection switch, and easy to realize the external connection lock control, to ensure safety operation.
2. Good combustion performance and easy maintenance
Carefully designed air mixed form, and fully ensure the safety of flame stability and full combustion
Combustion and combustion air quantity output can be set within the scope of regulation, by adjusting the output control and good burning effect;
Burner and stabilize flame device combination device, no need to disassemble the burner, can easily remove the internal component to repair and maintain;
