Rechargeable 48V 20AH lifepo4 battery pack for e-vehicle
Specification of 48V 20AH lifepo4 battery pack:
l Electrical Charateristics
Nominal Voltage |
48V |
Nominal Capacity |
20Ah |
|
Impedance (Max. at1000Hz) |
≤45mΩ |
Expected Cycle Life |
2000 cycles |
l Mechanical Characteristics
Height |
350±2mm |
Width |
150±2mm |
Length |
180±2mm |
Weight |
~12Kg |
l Operation Conditions
Charge Method |
Constant Current/Constant Voltage (CC-CV) |
Max. Charge Voltage |
58.4V |
Standard Charge Current |
4A |
Charge Temperature |
0℃~45℃ |
Max. Continuous Discharge Current |
30A |
Peak Instant Discharge Current |
50A, |
Peak Instant Discharge Time |
5 seconds |
Discharge Cut-off Voltage |
40.0V |
Discharge Temperature |
-20℃~65℃ |
Storage Temperature |
-20℃~45℃ |
Advantages:
l Attractive cycle life
l Extended safety performance
l Wide operating temperature range
l Unrivalled high temperature performance
l Green energy without metal contaminant
l High capacity
l Steady output voltage
l Little self-discharge
l Double safety protection
l Withstanding very high level of vibrations and shocks
Application:
Our factory:
