12v lifepo4 battery 300ah

Specifications

12v lifepo4 battery 300ah
ISO9001:2000, ISO1400, TS16949:2002 factory
2000 times deep cycle,80% capacity stay

12v   lifepo4 battery 300ah







1. Safety: safest LiFePO4 battery, CE UL approved, built-in BMS, none fire, none explosive

2. Clean and Green energy, no toxic material contained

3. Powerful: HP battery can discharge in 15C~20C

4. Long life cycle, > 2000 times deep cycle 80% capacity left,8 times of lead acid battery

5. No memory effect,highly efficient charge anytime, no reduction of capacity

6. Operation temperature: -20~70°C

7. Small size and light weight: 1/2 size of lead acid battery, 70% size of Ni-MH Ni-Cd battery,

1/2 weight of lead acid battery

8. Good performance at high temperature and high temperature resistance

9. Low self-discharge rate: < 3% monthly







1. Large-scale electric vehicles: electric bus, electric car, E-Tour Car

2. Light electric car: e-bike, electric scooter,e-motor, electric golf car, forklift, cleanness car, electric wheelchairs

3. E-tool: electric drill, electric saw, lawn mower and so on

4. Remote control cars, boat, aircraft, toys

5. Solar and wind power generation energy storage devices

6. Small medical equipment and portable equipment







Optimum LiFePO4 Battery/Lithium Battery Pack (12V 5Ah---400Ah)
5/10/20/25/30/40/50/60/80/100/120/150/200/300/400Ah
Item No.			OPT12005	OPT12010	OPT12020	OPT12025	OPT12030	OPT12040	OPT12050	OPT12060
Standard Capacity			5Ah	10Ah	20Ah	25Ah	30Ah	40Ah	50Ah	60Ah
Rated Voltage			12.8V
Discharge Cut-off Voltage			10.0V
Cell Model			IFR32650/32750
Casing Material			Steel Case for Single Cells
Self Discharge Rate			≤3% after one month
Life Cycles			80% left after 2000 times (with 1C constant charge and discharge deep cycle)
Max Continuous Discharge Current			2.5C
Max Charger Voltage			DC14.6V
Standard Charge Current			0.2C
Protection Function			Short-circuit &Over-current &Overcharge &Over-discharge &Undervoltage Protection
Product Size(mm)			151*51*93	135*85*85	182*76*167	184*75*135	118*175*175	190*165*175	190*165*175	350*168*179
Approx N.W			0.9Kg	1.3Kg	2.8Kg	3.5Kg	4.0Kg	5.5Kg	7.0Kg	8.0Kg
			OPT12080	OPT12100	OPT12120	OPT12150	OPT12200	OPT12200	OPT12300	OPT12400
Standard Capacity			80Ah	100Ah	120Ah	150Ah	200Ah	200Ah	300Ah	400Ah
Product Size(mm)                         (changeable)			260*170*215	330*170*220	339*173*212	502*262*242	502*262*242	360*220*262	520*262*242	560*360*200
Approx N.W			11Kg	16Kg	19Kg	24Kg	35Kg	38Kg	45Kg	65Kg





NOTE: PRICE= BATTERY PACK+BMS+HOUSING



 Normal Questions (for supplying you the best power supply solution)

1. What’s the application for battery packs?

2. What’s the load power for the battery? And peak load power?

3. Will you use the battery packs in parallel or in series?

4. Do you have special dimension requirement?

These are not all the possible needed information and please let me know if you have special requirement.(Skype:lovenge8023)



















Optimum Battery Co., Ltd/Optimumnano Energy CO.,LTD is one of the largest Lithium battery manufacturers withISO9001 and TS16949 certificates etc in China, specializing in LiFePO4 batteries with UL. CE. RoHS, IEC-62133 etc certifications for 7 years. We are the largest factory of producing cylindrical IFR32650-3.2V-5Ah/5.5Ah LiFePO4 cells in China.
