Drinking Paper Cup Machine
- 20 Unit / Units per Month
- Ningbo port
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | LUBAO | |
| Model Number | JZ-B | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Machine photo:
Introduction:
JBZ-B type paper cup shaper is the automatic machine with multi-ruuning positions.This machine ruuns a whole procedure of paper-feeding gluing oiling bottom-punching heating rolling romming rounding and tripping.The production of beverage and ice cream cups with single side adhibitting menbrane and other food cone-shaping containers.
Main techincal paraterm:
Model | JBZ-B |
Paper Cup Size ( Capacity) | 2oz-16oz |
Bottom Diameter of Paper Cup (mm) | 30mm-70mm |
Height of Paper Cup (mm) | 40mm-120mm (Standard size machine) |
Height of Paper Cup (mm) | 120mm-168mm (Special size machine) |
Required paper | Single side coated paper |
Paper Weight (g/m2) | 130 g/m2-280 g/m2 |
Ration productivity | 40-50 pcs/min |
Electric source | 220V 380V 50HZ |
Range of Temperature Control | 0-400 |
General power | 5KW |
Weight | 1400kg |
Size of outer package(L×W×H) | 2850×1350×1780MM |
Sample photo:
Workshop:
