New Ultrasonic water level sensor

Specifications

1. Waterproof;
2. High sensitivity;
3. Less power consumption;
4. High reliability;
5. Dustproof and Anti-corrosion;

1 . Working  voltage : 12~24VDC.

2 . Working current : <60mA.

3 . Detection distence : 1.0~4.0m(0.3*0.3   Plane target)

4 . Acoustic beam angle : < 10°

5 . Mode of signal output : digital signal : RS232,RS485 ; analog signal : 0-5V,0-10V,10mA-20mA

6 . Working temperature :  -20°C~+55°C

7 . Dimensions :  Φ26mm×28mm(thread)*104mm(Length does not include the plug.)
