Piezoelectric Actuator

Piezoelectric Actuator thumbnail-1
Piezoelectric Actuator thumbnail-2
Piezoelectric Actuator thumbnail-3
Piezoelectric Actuator thumbnail-4
Piezoelectric Actuator photo-1
Piezoelectric Actuator photo-2
Piezoelectric Actuator photo-3
Piezoelectric Actuator photo-4
US$ 0.1 - 1 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
HTW
Model Number:
HT070710
Contact Supplier Request Quote Chat Now
Chengdu Huitong West-Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Chnegdu China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Sichuan, China
Brand Name HTW
Model Number HT070710

1. Application range:

    (1)  All kinds of precision micro table.

    (2)  Adaptive optics deformable mirror.

    (3)  Optics micro processing system.

    (4)  Vehicle control.

    (5)  Biomedical engineering

    (6)  Scanning probe microscope

    (7)  Micropump and Microvalve



piezoelectric actuator









3. Main product specification:

Model No. Dimension  Nominal displacement Pushing force             @0 displacement  Stiffness Capacitance


A×B×H

    [mm] 		[μm@200V] (±10%)   [N@200V]   [N/μm]  [μF](±20%)
 HT0303/3  3*3*3  3  330  70  0.06
 HT0303/5  3*3*6  5  330  55  0.11
 HT0303/10  3*3*10  10  330  33  0.25
 HT0505/5  5*5*6  5  900  180  0.35
 HT0505/10  5*5*10  10  900  108  0.55
 HT0505/20  5*5*18  20  900  60  0.9
 HT0505/30  5*5*28  30  900  38  1.9
 HT0505/40  5*5*38  40  900  28  2.70
 HT0707/10  7*7*10  10  1800  216  1.0
 HT0707/20  7*7*18  20  1800  120  1.9
 HT0707/30  7*7*28  30  1800  77  3.0
 HT0707/38  7*7*36  38  1800  68  3.2
 HT0707/50  7*7*48  50  1800  51  4.5
 HT1010/10  10*10*10  10  3600  450  2.0
 HT1010/20  10*10*18  20  3600  250  3.5
 HT1010/30  10*10*28  30  3600  160  6
 HT1010/40  10*10*38  40  3600  118  9
 HT1010/50  10*10*48  50  3600  85  11
 HT1010/60  10*10*58  60  3600  60  13
 HT1414/10  14*14*10  10  7200  1000  3.5
 HT1414/20  14*14*20  20  7200  500  7
 HT1414/30  14*14*30  30  7200  333  11
 HT1414/40  14*14*40  40  7200  250  14
 HT1414/50  14*14*50  50  7200  180  18
 HT1414/60  14*14*60  60  7200  120  22
 HT1616/10  16*16*10  10  9500  1400  4.6
 HT1616/20  16*16*20  20  9500  700  9
 HT1616/30  16*16*30  30  9500  480  13.5
 HT1616/40  16*16*40  40  9500  350  18

3. Type:

    (1)  According to the shape of pile face:

           a. Square: (2×2×2)mm3—(20×20×150) mm3

           b. Rectangular: (3×2×2)mm3—(40×20×150) mm3   or

           c. Annular:  (3×3×φ1×3)mm3  or   (φ4×φ1×3)mm3—(30×30×φ16×60)mm3  or   (φ40×φ20×60)mm3

     (2) According to the packaging:

           a. Simple insulation package.

           b. Metal shell package.

 4. we can design and mnufacture according to customer's requirements.
