Help CenterHigh Frequency Ultrasonic Sensor
Related Products
-
EFR-40RS18A, Parking Sensor With High ReliabilityUS$ 1 - 10MOQ: 1 Piece -
High-power Piezoelectric CeramicNegotiableMOQ: 1000 Pieces
-
EFR-40/48/58RS16B1-GR, Ultrasonic Sensor With High ReliabilityUS$ 1 - 10MOQ: 1 Piece
-
Sell EFR-40/48/58RS18A Parking SensorUS$ 1 - 3MOQ: 1000 Pieces
-
We Supply High-power Ultrasonic TransducerNegotiableMOQ: 1000 Pieces
Specifications
Features:1. Waterproof;
2. High Sensitivity;
3. Less Power Consumption;
4. High Reliability;
Features:
1.Waterproof;
2. High Sensitivity;
3. Less Power Consumption;
4. High Reliability.
5. Small Angle;
6. Wide temperature range, dirty resistant;
7. Flame retardant;
Applications:
To test Object position, Liquid depth, Distance, etc.
Specifications:
| Parameters | Specification |
Frequency (kHz) |
110±5 |
Capacity (pf) |
1200±15% |
Ring Time (ms) |
≤0.8 |
S.P.L (dB) |
110±5 |
Sensitivity (dB) |
85±5 |
Angle (°) |
7±2 |
Max. Input Voltage (Vp-p) |
400 |
Operating Temp. Range |
-20+60 |
Storage Temp. Range |
-35+70 |
Weight (g) |
20.5 |
