1620mm*2500mm large format printer for glass/acrylic/wood moving door1.1620mm*2500mm
2.150mm max printing height
3.useful
1620mm*2500mm large format printer for glass/acrylic/wood moving door
Model: SK-UV1625
Features
1. Large format, high stability
2. Max printing size: 1620mm*2500mm
3. Max printing height: 150mm
4. Printing resolution: 2880dpi*1440dpi
5. Fast working speed: 540dip*720dip 6 pass 10.5 meters/hour
6. 8 color ink tank
7. Curable method: LED light curing, 20000 hours curing lift time
8. Nozzle cleaning methods: automatic cleaning
9. Printed image will no fade forever
Excellence:
1. LED-UV flatbed printer, with ultra-high precision, one time completed printing characteristic, using the advanced LED UV lamp curing technology, with can make the ink dry immediately, and with the concave and convex feeling effect, without pre-coating process, greatly improved production efficiency!
2. No producer prints fast and low cost! Available output software, supports a variety of file formats!
3. Computer color directly, and with professional color management software, can be color-anytime, anywhere, at no extra cost!
4. Single step can be done! The printed image can be taking immediately! Can save time and effort!
5. Full color image, once completed, great printed image!
6. Only 30 minutes, you could operate the machine by yourself! No need special training!
Suit for:
Plastic bottons, metal bottons, glass handles, leather belts, PU leather belt, PVC, cotton cloth on it, glass, aluminum ceiling, wooden door, etc!
Technology parameter
Model |
SK-UV1625 |
Print Size(width-length) |
1620*2500mm (length can be produced according to customer requirement) |
Print thickness |
150mm( you can customize any thickness) |
Ink System |
Double 4 colors ---CC,MM,YY, KK |
Print precision |
2880DPI*1440DPI |
Nozzle Configuration |
180nozzle *8 colors,using intelligent transform ink technology |
Ink drop size |
Min 3.5 pl ink |
Platform way |
Sectional platform vacuum adsorption |
Print Speed |
540*720 6 pass 10.5 meters/h; 1440*1440(16pass) 3.0m 2/h |
Power Requirements |
110-220V, 50-60HZ work 800W, Standby 15W |
Work Environment |
Working temperature 15-35°C; operating humidity:20%-80%, storage humidity 5-85% |
Curable method |
LED light curing, max 20000 hours curing lifetime |
Operating Platform |
Windows 2000/XP,XPx64, Vista ,Vistax64, Mac OSX |
Interface Printing |
USB2.0/1.1 interface & 100 Base-T Ethernet interface |
Nozzle Cleaning Method |
Automatic cleaning |
Nozzle Protection Method |
Infrared automatic protection system |
Print Object Height Detection |
Intelligent induction, dual detection system |
Weight of Equipment |
400KG/450KG |
Device Dimension(l/w/h) |
3700mm*2400mm*1250mm |
Packing Size(l/w/h) |
3900mm*2800mm*1400mm |
Other model printers:
Model |
Max printing size |
SK-T4290 |
432mm*900mm |
SK-UV4290 |
432mm*900mm |
SK-UV6118 |
610mm*1700mm |
SK-UV2513 |
2500mm*1300mm |
If you interest in our products, please no hesitate to contact me ASAP!
