Shackle

Name: Shackle
Brand: Chenli
Availability: InStock

FOB Price

USD $1 - $20 / Unit

1000 Units(Min.Order)

Product Details

Place of Origin:

China

Brand Name:

Chenli

Model Number:

Bow G209

1.the materials is alloy steel
2.dip coating painting .galvanized hot dipped
3.G80
4.safety factor 4 times.testing load 2.5

FLAT SHACKLE

Working load limited:55t-1500t.
High quality structural alloy steel.
Proof testing losad:2times      55t-300t
                            1.5times    400t
                            1.33times  500t-1500t
The minimum breaking load is 4 times of the rating working
load.
Manufacturing method of the shackle used the swaging and
open die forging.
Heat freatment.
Non-destructive testing covered all the products.
Every shackle has the working load mark.
No need to use the lantern ring when the shackle was
connected with highstrength lifting belt,wire rope sling and
large radius's domed roof.
Staying quality of the wire rope sling has improved
obviously.
The shackle noumenon was galvanized and the pin roll is
blue.
Blue pin is the original product's quality mark of Juli.
